100*120mm Automatic Gabion Mesh Machine 3.2mm Wire for Gabion Box, Mattress

Place of Origin China
Brand Name Jinlida
Certification CE, ISO9001, SGS
Model Number LNWL-4h
Minimum Order Quantity 1 set
Packaging Details Nude packing and will be fixed by iron wire in 40' container
Delivery Time 45 days
Payment Terms L/C, T/T
Supply Ability 200 sets per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Gabion Mesh Machine LNWL4 Wire Diameter 3.2mm
Mesh Size 100x120mm Mesh Width 4300mm
Capacity 225m/h Motor 22kw
High Light

100*120mm Gabion Mesh Machine

,

Automatic Gabion Mesh Machine

,

3.2mm Gabion Mesh Machine

Leave a Message
Product Description



Quick Details:



        The weaving mesh speed of LNWL4 adds to 60 moves per minute, in this way, efficiency improves one third of old machines.



Packing&Delivery:



        Packing Details: Nude packing and will be fixed in the 40'container by iron wire


        Delivery Time: 45 days



Specifications:

Style Mesh Size Width Wire Diameter Spindle Speed Power of Motor Theoretic Output
(mm) (mm) (mm) (r/min) (kw) (m/h)
LNWL4-60 60×80 4300 1.6-3.2 25 22 165
LNWL4-80 80×100 1.6-4.0 195
LNWL4-100 100×120 1.6-4.0 225
LNWL4-120 120×150 1.6-4.2 20 255



Description:

      1. The wire netting machine we made adopts PLC control system and automatic oil system.

      2.It can weave 3.0mm wire mesh easily like normal machine weave 2.4mm wire mesh, and speed is also quickly as normal style.



      3.Nodular cast iron is used by new machine, good toughness and wear-resisting.


      4.Adjustment of structure no longer be used in rack and big connecting rod, easier and more reliable to operate.





Advantages:



  1.According to the products and raw materials appropriately adjust the speed and reduce rate of broken.



  2. Mesh is well-arranged and distributed evenly and orderly.



      3.Simple operation.
