Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box

Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box

  • High Light

    Wire Cage Gabion Machine

    ,

    2.6mm Gabion Machine

    ,

    2.6mm wire mesh manufacturing machine

  • Product Name
    Gabion Mesh Machine
  • Mesh Width
    4300mm
  • Mesh Size
    84*110mm
  • Wire Diameter
    2.6mm
  • Speed
    195m/h
  • Application
    Gabion Box Stone Cage
  • Place of Origin
    China
  • Brand Name
    Jinlida
  • Certification
    CE, ISO
  • Model Number
    LNWL4
  • Minimum Order Quantity
    1 set
  • Packaging Details
    Nude packing and will be fixed in 40 OT.
  • Delivery Time
    40 days

Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box

Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box

Jinlida insists on innovating,we have studied and produced automatic gabion production line,it can make gabion box automatic from mesh weaving to edge winding mesh sheet,this system will save labour force and improve output,it has high efficiency.


Quick Details

1. The weaving mesh speed of LNWL4 adds to 60 moves per minute, in this way, efficiency improves one third of old machines.

2. For high corrosion resistance,zinc and PVC,Galfan coated is available



Specifications


Style Mesh Size Width Wire Diameter Spindle Speed Power of Motor Theoretic Output
(mm) (mm) (mm) (r/min) (kw) (m/h)
LNWL4-60 60×80 4300 1.6-3.2 25 22 165
LNWL4-80 80×100 1.6-4.0 195
LNWL4-100 100×120 1.6-4.0 225
LNWL4-120 120×150 1.6-4.2 20 255


Description

1. It uses big worm gear case, it reduces oil temperature to avoid worm burning hot. And the force of pulling mesh is greater.
2. It is the ideal machinery that weaves big signification,breadth portal arm,thick silk gabion mesh.
3. The machine is supposed to be in continuous and smooth operation, saving much labour force.It has low noise and automatic stop system.If coiling wires are ran out,the machine will stop automatically.
 Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box 0  Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box 1

Application
The gabion box machine is the professional equipment that produces hexagonal mesh, its product is widely used in
petroleum, building, farming and chemical engineering industry, keep warm piping and other piping,
still be applicable to the river embankment protection, coast to manage,
and the assisting of tunnel engineering and breakwater establish the etc.
   Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box 2  Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box 3


Advantages
1. We provide12months warranty to help install the machines in your country,and also can supply all the spare parts at cost price if customers need.
2. We offer fine quality, competitive prices,prompt delivery and a satisfying service.
3.Jinlida has rich experience and professional skills to meet your needs and satisfy your requirements.


Galvanized 2.6mm Wire Gabion Machine 103*130mm Mesh for Gabion Box 4
