3 Twisted Hexagonal Wire Netting Machine 22Kw For Gabion Mesh , 4300mm Width
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Wire Netting Machine | Mesh Max Width | 4300mm |
|---|---|---|---|
| Twist | 3twist, 5 Cross | Power | 22kw |
| Product | Gabion Mesh | Warranty | 1 Year |
| High Light | warping machine,large diameter hexagonal mesh machine |
||
Product Description
3 Twisted Hexagonal Wire Netting Machine 22Kw For Gabion Mesh , 4300mm Width
Quick Detail:
1.Gabion making Machine is the professional machine to produce inerratic gabion mesh ,the mesh can be
used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir
and other construction project.
2. it is the good material to prevent or control flood.
Description:
The LNWL series 3 gabion mesh machine can produce both double twisted mesh and three twisted mesh in
the same gabion mesh machine, it is very economy. A set of gabion making machine includes four main
parts: Mesh weaving machine, roll mesh machine, coiling spring machine, warping machine.
The LNWL-3 series gabion mesh machines have been designed to make gabion mesh of various widths
and mesh sizes; we can produce the machine as your size.
Three Series type hexagonal wire netting machine
This type machine is using spiral coil. And the twist could be double twisted and three twisted as below
picture.
Pic 1:double twisted mesh and three twisted mesh
Pic 2:Heavy duty hexagonal wire netting machine for GABION
This machine is for making GABION mesh.
Applications:
Gabion making Machine is the professional machine to produce inerratic gabion mesh ,the mesh can be
used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir
and other construction project, and it is the good material to prevent or control flood.
Specifications:
| Specifications of 3 series gabion mesh machine | ||||||
| Style | Size | Width | Diameter | Spindle Speed | Power of Motor | Theoretic Output |
| (mm) | (mm) | (mm) | (r/min) | (kw) | (m/h) | |
| LNWL43-60-3 | 60×80 | 4300 |
1.6-3.2 | 25 | 22 | 165 |
| LNWL43-80-3 | 80×100 | 1.6-4.0 | 195 | |||
| LNWL43-100-3 | 100×120 | 1.6-4.0 | 225 | |||
| LNWL43-120-3 | 120×150 | 1.6-4.2 | 20 | 255 | ||
Competitive Advantage:
1. JINLIDA company invented the first special equipment of double twisted wire netting making machine in China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area of gabion machine making for 15 years.
2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to
process, so the quality can be ensured.
3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our technician to help install the machines in your country, and also could supply all the spare parts with cost price if customer need.
