25rpm Galvanized PVC Coated Gabion Netting Machine

25rpm Galvanized PVC Coated Gabion Netting Machine

  • High Light

    PVC Coated Gabion netting Machine

    ,

    25rpm Gabion netting Machine

    ,

    25rpm Galvanized netting Machine

  • Model Number
    LNWL43-120-2
  • Weight (KG
    15000
  • Power (kW)
    22
  • Warranty
    1 Year
  • Spindle Speed
    25
  • Specification
    6300*1400*2400
  • Twist
    3 Cross
  • Application
    River Course
  • Place of Origin
    Jiangsu, China
  • Brand Name
    Jinlida
  • Certification
    CE,SGS
  • Model Number
    LNWL43-120-2
  • Minimum Order Quantity
    one set
  • Price
    USD35000-40000
  • Packaging Details
    Nude packing and will be fixed in the 40'container by iron wire
  • Delivery Time
    50 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    200 Set/Sets per Year

25rpm Galvanized PVC Coated Gabion Netting Machine



Quick Details

Place of Origin:Jiangsu,China(Mainland)

Brand Name:JINLIDA

Model Name:LNWL43-120-2

Certification:CE ISO

Application:gabion box,gabion machine

Color:cuotomized

Mesh Size:120×150mm

Width:4300mm

Weight:15000kg

After-sales Service: Engineers available to service machinery overseas



Packaging & Delivery

Packaging
Size 7200(L) * 1400 (W) * 2400 (H)
Weight 15 T
Packaging Details Nude packing and will be fixed in the 40'container by iron wire, make sure it is safe on passage.

Product Application

Gabion making machine is the professional machine to produce hexagonal mesh, the mesh can be used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir and other construction project. And it is one of the best material against flooding.

Specification

Style Mesh size Width Wire diamater Spindle Speed power of motor Theoretic output
(mm) (mm) (mm) (r/min) (kw) (m/h)
LNWL43-60-3ZX 60X80 4300 1.6-3.2 25 22 165
LNWL43-80-3ZX 80X100 1.6-4.0 195
LNWL43-100-3ZX 100X120 225
LNWL43-120-3ZX 120X150 1.6-4.0 20 255



Advantages

1.The LNWL-3 series gabion mesh machine have been designed to make gabion mesh of various widths and mesh sizes;we can produce the machine as your size.

2.This gabion mesh machine's structure is simpleness,it can make the machine weaving mesh more easier.

3.The caoability is stabilization,all the points of iunction have bearing to fix,the parts will hard-wearing,lengthen machine life.

4.Thw mesh that 3 series mahchine weave,the part of twist will be longer that 2 aeries machine,so when the mesh need edge curl that using the selvedge machine,it will going easily and smoothly.

5.The fastest delivery time.

6.The fastest service.

7.The most reasonable price.
