5 Twist Hexagonal  22kw 165m/H Gi Wire Net Making Gabion Machine

5 Twist Hexagonal 22kw 165m/H Gi Wire Net Making Gabion Machine

  • High Light

    Wire Net Making Gabion Machine

    ,

    165m/H Gi Wire Net Making Machine

    ,

    5 twist Wire Net Making Machine

  • Weight(KG)
    16000
  • Specification
    6300*1400*2400mm
  • Application
    River Course
  • Spindle Spee
    25r/min
  • Theoretic Ou
    165m/h
  • Wire Diameter(mm)
    1.6-4.0mm
  • Power(KW)
    22
  • Warranty
    1 Year
  • Mesh Size
    60x80mm
  • Model Numb
    LNWL43-60-2
  • Place of Origin
    Jiangsu,China
  • Brand Name
    Jinlida
  • Certification
    SGS,CE
  • Model Number
    LNWL43-60-2
  • Minimum Order Quantity
    1 set
  • Price
    USD37000-45000 Per unit
  • Packaging Details
    Nude packing and will be fixed in the 40'container by iron wire
  • Delivery Time
    50days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    200 Set/Sets per Year

5 Twist Hexagonal 22kw 165m/H Gi Wire Net Making Gabion Machine

Quick Detail:


Jinlida series machine is designed to make hexagonal wire mesh of various widths and mesh sizes, we can produce the machine as your size.

Packing&Delivery:

Packing Details: Nude packing and will be fixed in the container by wire.
Lead Time: 50 days


Main technical parameter:
Style Mesh Size Width Wire Diameter Spindle Speed Twist Power of Motor Theoretic Output
(mm) (mm) (mm) (r/min) (r) (kw) (m/h)
LNWL43-60-2 60 x 80 4300 1.6-3.2 25 3 22 165
LNWL43-80-2 80 x 100 1.6-4.0 195
LNWL43-100-2 100 x 120 1.6-4.0 225
LNWL43-120-2 120 x 150 1.6-4.2 20 255
LNWL43-60-3 60 x 80 4300 1.6-3.2 25 5 22 165
LNWL43-80-3 80 x 100 1.6-4.0 195
LNWL43-100-3 100 x 120 1.6-4.0 225
LNWL43-120-3 120 x 150 1.6-4.2 20 255


Description:

1.The mesh weaving machine we made adopts PLC control system and automatic oil system.

2.The wire mesh machine uses big worm gear case, it reduces oil temperature to avoid worm burning hot. And the force of pulling mesh is greater.


3.For high corrosion resistance, zinc and PVC, Galfan coated is available.



Product Display:

5 Twist Hexagonal  22kw 165m/H Gi Wire Net Making Gabion Machine 0  5 Twist Hexagonal  22kw 165m/H Gi Wire Net Making Gabion Machine 15 Twist Hexagonal  22kw 165m/H Gi Wire Net Making Gabion Machine 2  5 Twist Hexagonal  22kw 165m/H Gi Wire Net Making Gabion Machine 3



Competitive Advantages:

1.Jinlida has rich experience and professional skills to meet your needs and satisfy your requirements.

2.We have 15 years export experience establishing trade with more than 30 countries.

3.All the parts of gabion mesh machine are produced by our Jinlida, no parts were sending outside to produce, so we can guarantee the quality.



4.It has the function of frequency control of motor speed according to different of wire diameter.



5.It can save about 30% energy.



Application:

The product has widely purpose,with its good corrosion resistance and oxidation resistance, serves well as strengthen,

protection and temperature keeping materials in the form of mesh container, stone cage, isolation wall, boiler cover or poultry

fence in construction, petroleum, chemical, breeding, garden and food processing industries.


FAQ

Q:Are you trading company or manufacturer ?
A: Our factory is the professional manufacturer.

Q: How long is your delivery time?
A: Generally it is 40-50 days if the goods are in stock.

Q: What standard machine contains?
A: A set of gabion mesh machine is composed of hexagonal wire mesh machine, wire tension device, netting winding machine and spring coiling machine.
