High Speed Wire Mesh Cutting Machine

High Speed Wire Mesh Cutting Machine

  • High Light

    steel wire cutting machine

    ,

    automatic wire cutting machine

  • Place of Origin
    China
  • Brand Name
    JINLIDA
  • Model Number
    WMC-100
  • Minimum Order Quantity
    1
  • Price
    Competitive price
  • Packaging Details
    Nude packing
  • Delivery Time
    30 days
  • Payment Terms
    L/C,T/T
  • Supply Ability
    100 sets/a year

High Speed Wire Mesh Cutting Machine

High Speed Wire Mesh Cutting Machine





Quick Detail:

1. The diameter of wire: 4.0mm

2.Mesh Width: 4300mm

4.Motor Power: 7.5kw

5.Wieght: 6t

6. Dimensions: 5000x1800x1600mm





Gabion Mesh Sheet Cutting Machine

The Gabion Mesh Cutting Machine is using for gabion mesh's cutting; it is an essential machine for gabion

production line. Netting Sheet Cutting Machinery Cutting Sheet without manual work





Main Specifications:

1. The diameter of wire: 4.0mm

2.Mesh Width: 4300mm

4.Motor Power: 7.5kw

5.Wieght: 6t

6. Dimensions: 5000x1800x1600mm





Advantage:

1. The machine's frame is rugged, with the return of nitrogen cylinder, it is steady and rapid

2. With stepless travel features, the upper and lower blade's clearance can be adjusted with handle, it is

easy to adjust.

3. Fence and electrical chain to ensure safe operation

4. Closed loop control system is composed of numerical controls and position encoder, it is high speed,

high accuracy, good stability

5. CNC system has the accuracy and automatic detection of a variety of additional features





Mesh Cutting Machine Working



High Speed Wire Mesh Cutting Machine 0



Products of Mesh Cutting Machine

High Speed Wire Mesh Cutting Machine 1





Competitive Advantage:

1. All the parts of netting sheet cutting machine are processed by our own factory; no parts were sending to

outside to process, so the quality can be ensured.



2. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
