SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine

SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine

  • High Light

    2.3mm diameter Gabion Mesh Machine

    ,

    TUV gabion Mesh Machine

    ,

    TUV gabion box machine

  • Width
    2.3m
  • Additonal Device
    Infrared Ray Safety
  • Color
    Customized
  • Place of Origin
    China
  • Brand Name
    Jinlida
  • Certification
    TUV
  • Model Number
    LNWL23-80-2
  • Minimum Order Quantity
    1
  • Price
    Competitive price
  • Packaging Details
    Nude packing
  • Delivery Time
    40 days
  • Payment Terms
    L/C,T/T
  • Supply Ability
    200 sets/year

SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine

2.3m Width Automatic Gabion Mesh Machine Infrared Ray Safety , SGS / TUV Certificate



Additional Device:

1. PLC control system touch screen(Option)

2. Infrared ray safety(Option)

3. Automatic stop system (Option)



Description:

1. Invented first double twist gabion mesh making machine in China

2. Apply for national patents, number is ZL99229381.2 and ZL00267066.5

3. SGS,TUV certificate



Gabion mesh making machine

Jinlida series mesh making machine is designed to make hexagonal wire mesh of various widths and mesh sizes. We have 15 years export experience establishing trade with more than 30 countries, and Maccaferri, DEACERO, NOVA-S a.s.& DKG and TFS HOLDINGS are our long-standing relationship customers.



Pic 1 Mesh Making Machine

 SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine 0



SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine 1



Specifications:

Style Mesh size Width Wire diamater Spindle Speed Twist power of motor Theoretic output
(mm) (mm) (mm) (r/min) (r ) (kw) (m/h)
LNWL23-60-2 60X80 2300 1.6-3.2 25 3 11 165
LNWL23-80-2 80X100 1.6-4.0 3 195
LNWL23-100-2 100X120 1.6-4.0 3 225
LNWL23-120-2 120X150 1.6-4.2 20 3 255
LNWL33-60-2 60X80 3300 1.6-3.2 25 3 15 165
LNWL33-80-2 80X100 1.6-4.0 3 195
LNWL33-100-2 100X120 1.6-4.0 3 225
LNWL33-120-2 120X150 1.6-4.2 20 3 255
LNWL43-60-2 60X80 4300 1.6-3.2 25 3 22 165
LNWL43-80-2 80X100 1.6-4.0 3 195
LNWL43-100-2 100X120 1.6-4.0 3 225
LNWL43-120-2 120X150 1.6-4.2 20 3 255
LNWL43-60-3 60X80 1.6-3.2 25 5 165
LNWL43-80-3 80X100 1.6-4.0 5 195
LNWL43-100-3 100X120 1.6-4.0 5 225
LNWL43-120-3 120X150 1.6-4.2 20 5 255





























































Pic 2&3 Wire tension device&Netting winding machine

 SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine 2 SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine 3

 Pic 4 Spring coiling machine

SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine 4



JINLIDA Series Prduction Line

SGS TUV Certificate 2.3mm Diameter Gabion Mesh Machine 5



Competitive Advantages:

 1. All the parts of netting sheet cutting machine are processed by our own factory, no parts were send to

outside to process, so the quality can be ensured.

 2. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
