TUV  7.5kw PLC Wire Mesh Cutting Machine Open Formular Drive

TUV 7.5kw PLC Wire Mesh Cutting Machine Open Formular Drive

  • High Light

    PLC Wire Mesh Cutting Machine

    ,

    TUV Wire Mesh Cutting Machine

    ,

    TUV Wire Mesh cutter

  • Weight(kg)
    12000
  • Control System
    PLC
  • Wire Diameter(mm)
    1.6-4.0mm
  • Size
    5400 X 1970 X 1400mm
  • Power(kw)
    22
  • Color
    Customized
  • Warranty
    1 Year
  • Model Number
    QWJ-100
  • Place of Origin
    Jiangsu,China
  • Brand Name
    Jinlida
  • Certification
    SGS,CE
  • Model Number
    QWJ-100
  • Minimum Order Quantity
    1 set
  • Price
    Competitive price
  • Packaging Details
    Nude packing and will be fixed in the 40'container by iron wire
  • Delivery Time
    30-50days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    200 Set/Sets per Year

TUV 7.5kw PLC Wire Mesh Cutting Machine Open Formular Drive

Quick Details
Place of Origin:Jiangsu,Chine(Mainland)
Brand Name:Jinlida
Model Number:QWJ-100
Certification:SGS.TUV
Color:Green
Condition:new
Power:7.5kw
Weight:6000kg
Sfter-sales Service:Engineers available to service machinery overseas


Supply Ability
Supply Ability:300 Sets/ per Year

Packaging & Delivery
Packaging Details:Nude packing and will by fixed in the container by iron wire
Port:Shanghai
Lead Time:40 days


Features
1.The machine adopts open-formula drive.It is beautiful.The institution is tighten.The operation is simple.
2.The upper blade holder is welded by steel plates,high strength,light weight,and high shearing accuracy.
3.The force of fixing device is strong and even.The machine can run smoothly.
4.The machine is equipped with forve-and-aft stock stop,easy operation.


Main Parameter

The Diameter of Wire 4.0mm Mesh Width 4500mm
Shearing Angle 1°30' Certification SGS,TUV
Power 7.5kw Warrantly 1 year
Spindle Speed 1460r/min Dimension 5400 x 1970 x 1400mm
Belonging Gabion production line MOQ 1 Unit
Model Number QWJ-100 Weight 6000kg
Delivery 40 days Port Shanghai
