Automatic Gabion Making Machine For Mattress 66*90mm Low Noise

Product Details

Place of Origin: China

Brand Name: JINLIDA

Certification: ISO9001, ISO14000

Model Number: LNWL4

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Competitive price

Packaging Details: Nude packing and will be fixed in the 40'container by iron wire

Delivery Time: 40 days after order confirmed

Payment Terms: L/C,T/T

Get Best Price
Highlight:

Mattress Gabion Basket Machine

,

Low Noise Automatic Gabion Machine

,

Automatic Gabion Basket Making Machine

Name:
Gabion Machine
Mesh Width:
3300mm
Mesh Size:
66*90mm
Wire Diameter:
2.6mm
Sopeed:
165m/h
Application:
Mattress
Name:
Gabion Machine
Mesh Width:
3300mm
Mesh Size:
66*90mm
Wire Diameter:
2.6mm
Sopeed:
165m/h
Application:
Mattress
Automatic Gabion Making Machine For Mattress 66*90mm Low Noise

Automatic Gabion Machine for Mattress 66*90mm Gabion Basket, Low Noise



Quick Detail:

1. Gabion machine is also known as hexagonal wire netting machine, which is the professional machine to produce hexagonal wire mesh.

2. Jinlida series machines are designed to make gabion mesh of various widths and mesh sizes, we can produce the machine as your size.


Why chose Jiangyin Jinlida for your projects?

1. Jinlida is the earliest and largest manufacturer of gabion structures in China.

2. Member of Chinese Hydraulic Engineering Society(CHES).

3. Member of China Institute of Water Resources.

4. Editor unit of China gabion engineering and technology standard.

5. The only one enterprise recommended by China Ministry of Water Resources in the field of gabion structures.

6.Strictly implement and meet international standard ASTM STANDARD or BS EN STANDARD and pass ISO &

SGS quality certificate system.



Specifications:

special mesh size available on request.

-4H/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

五绞

five twist

拉网辊

Mesh roller

Ø

-4H

双绞捻网速度double twist knitting speed

-4HS

五绞捻网速度

five twist knitting speed

60*85/ 28mm Ø180/ 5

















25 20
66*90/ 28mm Ø191/ 5

















25 20
70*90 /30mm Ø191/ 5 70*90/ 45mm Ø215/ 5 70*105/ 55mm Ø203.8/4 25 20
80*103/ 32mm Ø215 / 5 80*115/ 45mm Ø203/ 4 80*105/ 55mm Ø203/ 4 25 20
88*105/ 32mm Ø218/ 5 88*115/ 45mm Ø203/ 4 88*105/ 55mm Ø203/ 4 25 20
90*100/ 32mm Ø218/ 5 90*115/ 45mm Ø203/ 4 90*105/ 55mm Ø203/ 4 25 20
100*120/ 32mm Ø242/ 5 100*125 /45mm Ø217/ 4 100*115/ 55mm Ø217/ 4 25 20
110*140/ 32mm Ø219/ 4 110*126/ 45mm Ø218/ 4 110*116/ 55mm Ø218/ 4 25 20
120*140/ 32mm Ø219/ 4 120*140/ 45mm Ø295/ 5 120*130/ 55mm Ø295/ 4 25 20
Note:

1. -4H:不带伺服程序控制,-4HS:带伺服程序控制.

-4H: without servo program control, -4HS: with servo program control.

2. Ø拉网辊外径后面-4或-5为圆周上的拉网齿等分.

Mesh roller item: ‘4’ or ‘5’ means thorn nails equal parts number(how many nails rows of one roller ).

3. 网孔规格-32,-45,-55为网孔绞合部分的长度尺寸.

Double twist and five twist item: ‘32mm’, ‘45mm’, ‘55mm’ is twist length.

4. -4H型机设定每分钟理论生产速度为25个双绞网孔.

-4H machine theoretic output: 25 double twist mesh hole every minute.

5. -4HS型机设定每分钟理论生产速度为20个五绞网孔.

-4HS machine theoretic output: 20 five twist mesh hole every minute.





Packing&Delivery:

Packing Details: Nude packing and will be fixed in the 40'container by iron wire

Lead Time:40 days

Automatic Gabion Making Machine For  Mattress 66*90mm Low Noise 0  Automatic Gabion Making Machine For  Mattress 66*90mm Low Noise 1



Machine Features

1. Adopted with central automatic lubrication system, so as to make feeding guideway to have the good performance for little resistance, little friction, good lubrication and long life etc.

2. PLC control system touch screen is available for the hexagonal wire mesh machine.

3. Automatic stop system saves much labor force.

Automatic Gabion Making Machine For  Mattress 66*90mm Low Noise 2 Automatic Gabion Making Machine For  Mattress 66*90mm Low Noise 3 Automatic Gabion Making Machine For  Mattress 66*90mm Low Noise 4



Advantages

1.We have persevered in this area of gabion mesh machine for 15years.Jinlida invented the first special equipment of double twist wire netting machine in China(ZL99229381.2 and ZL00267066.5).

2.Every part of gabion mesh machine is high quality,they are assembled by skilled workers who have years of experience.

3.We provide 12months guarantee for all the equipment,and if customers need,we will arrange our professional technician to help install the machines in your country,and also can supply all the spare parts at cost price if customers need.
