ISO9001 1.6mm  Flooding Protection Wire Netting Machine

ISO9001 1.6mm Flooding Protection Wire Netting Machine

  • High Light

    Flooding Protection Wire Netting Machine

    ,

    ISO9001 Wire Netting Machine

    ,

    ISO9001 wire cage machine

  • Production Capacity
    200 Sets/Year
  • Weight(KG)
    15000
  • Specification
    6400*1500*2400mm
  • Application
    River Course
  • Theoretic Ou
    195m/h
  • Spindle Speed
    25r/min
  • Mesh Size
    80*100mm
  • Type
    LNWL43-80-2
  • Twist
    3 Cross
  • Wire Diamet
    1.6-4.0mm
  • Place of Origin
    Jiangsu,China
  • Brand Name
    Jinlida
  • Certification
    SGS,CE
  • Model Number
    LNWL43-80-2
  • Minimum Order Quantity
    1 set
  • Price
    USD37000-45000 Per unit
  • Packaging Details
    Nude packing and will be fixed in the 40'container by iron wire
  • Delivery Time
    50days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    200 Set/Sets per Year

ISO9001 1.6mm Flooding Protection Wire Netting Machine

Product Application

Gabion making machine is the professional machine to produce hexagonal mesh, the mesh can be used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir and other construction project. And it is one of the best material against flooding.

Product Name gabion mesh machine Material iron
Color green Certification CE, ISO9001
Control PLC Power 22kw
Weight 15t Mesh Size 80×100mm
Width 4300mm Wire Diameter 1.6-5.0mm
Spindle Speed 25 r/min Twist 2 twist, 3 cross
Theoretic Output 195 m/h Patent ZL99229381.2 and ZL00267066.5



Product Application



Model Mesh Size Max.Width Wire diameter

Twisting

Number

Main drive shaft speed Motor Capacity Theoretical speed
/ mm mm mm / / / m/h
LNWL23-60-2 60*80 2300 1.6-3.0 3 25 11 165
LNWL23-80-2 80*100 1.6-3.0 195
LNWL23-100-2 100*120 1.6-3.5 225
LNWL23-1200-2 120*150 1.6-3.2 20 255
LNWL33-60-2 60*80 3300 1.6-2.8 25 15 165
LNWL33-80-2 80*100 1.6-3.0 195
LNWL33-100-2 100*120 1.6-3.2 225
LNWL33-120-2 120*150 1.6-3.5 20 255
LNWL43-60-2 60*80 4300 1.6-2.8 25 22 165
LNWL43-80-2 80*100 1.6-3.0 195
LNWL43-100-2 100*120 1.6-3.0 225
LNWL43-120-2 120*150 1.6-3.2 20 255
LNWL43-60-3 60*80 4300 1.6-2.8 5 25 22 165
LNWL43-80-3 80*100 1.6-3.0 195
LNWL43-100-3 100*120 1.6-3.0 225
LNWL43-120-3 120*150 1.6-3.2 20 255



Main Features

1) Adopted with central automatic lubrication system, so as to make feeding guideway to have the good performance for little resistance, little friction, good lubrication and long life etc.

2) PLC control system touch screen is available for the hexagonal wire mesh machine.

3) Automatic stop system saves much labor force.


Packing Details

Packing Details: Nude packing and will be fixed in the 40'container by iron wire

Lead Time: 50 days




Product Display

ISO9001 1.6mm  Flooding Protection Wire Netting Machine 0   ISO9001 1.6mm  Flooding Protection Wire Netting Machine 1
Explanation

1.Adopted with central automatic lubrication system, so as to make feeding guideway to have the good performance for little resistance, little friction, good lubrication and long life etc.

2.We have persevered in this area of gabion mesh machine for 15years. Jinlida invented the first special equipment of double twisted wire netting machine in China(ZL99229381.2 and ZL00267066.5).


Competitive Advantages

1.Our factory is the professional manufacturer of the hexagonal wire mesh machine, and our factory is initiative for gabion mesh machine in China.

2.All machines showed in global market and made-in-china are from JIinlida.

3.The LNWL2 series mesh weaving machines have been designed to make gabion mesh of various widths and mesh sizes. If you want to buy advanced machine and get best after-sales-service, please contact me immediately.
