Three Twist Wire Netting Machine

Three Twist Wire Netting Machine

  • High Light

    gabion weaving machine

    ,

    large diameter hexagonal mesh machine

  • Place of Origin
    China
  • Brand Name
    JINLIDA
  • Model Number
    LNWL43-100-3
  • Minimum Order Quantity
    1
  • Price
    Competitive price
  • Packaging Details
    Nude packing
  • Delivery Time
    50 days
  • Payment Terms
    L/C,T/T
  • Supply Ability
    200 sets/a year

Three Twist Wire Netting Machine

Three Twist Wire Netting Machine


Quick Detail:
1.Gabion making Machine is the professional machine to produce inerratic gabion mesh ,the mesh can be
used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir
and other construction project.
2. it is the good material to prevent or control flood.


Descrition:
The LNWL series 3 gabion mesh machine can produce both double twisted mesh and three twisted mesh in
the same gabion mesh machine, it is very economy. A set of gabion making machine includes four main
parts: Mesh weaving machine, roll mesh machine, coiling spring machine, warping machine.


Features for lnwl-3 gabion machine

1. The LNWL-3 series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes; we can produce the machne as your size.

2. This new 3 series gabion mesh machines structure is simpleness, it can make the machine weaving mesh more easier.

3. The capability is stabilization, all the points of iunction have bearing to fix, the parts will hard-wearing, lengthen machine life.

4. The mesh that 3 series machine weave, the part of twist will be lnger that 2 series mchine, so when the mesh need edge curl that using the selvedge machine, it will going easily and smoothly.

This type machine is using spiral coil. And the twist could be double twisted and three twisted as
below picture.
Three Twist Wire Netting Machine 0 Three Twist Wire Netting Machine 1 Three Twist Wire Netting Machine 2
Pic 1:double twist mesh Pic 2: three twist mesh Pic 3: Gabion box application


Applications:

Gabion making Machine is the professional machine to produce inerratic gabion mesh ,the mesh can be
used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir
and other construction project, and it is the good material to prevent or control flood.


Specifications:

1. Mesh sizes: 120X150mm

2. twist: double twist & three twist

3. Max. netting width: 4300mm

4. Max. galvanized wire diameter: 3.2mm

5. Max PVC wire diameter: 4.2mm

6. Spindle Speed:25r/min

7. Power: 22Kw

8. Size: 7200 x 1400 x 2400mm

9. Weight: 15MT

10. Theoretic output: 255m/hr

11. Automatic stop system (option): when the coiling finished or wire broken, the machine will stop

automatically

12. Infrared ray safety protection system (option)

13. Automatic oil system


Competitive Advantage:

1. JINLIDA company invented the first special equipment of double twisted wire netting making machine in
China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area
of gabion machine making for 15 years.

2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to
process, so the quality can be ensured.

3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare parts with cost
price if customer need.
