Automatic Three Twist Gabion Wire Mesh Weaving Machine Width 4.3m

Place of Origin China
Brand Name Jinlida
Model Number LNWL43-100-3
Minimum Order Quantity 1
Price Competitive price
Packaging Details Nude packing
Delivery Time 50 days
Payment Terms L/C,T/T
Supply Ability 200 sets/a year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Hexagonal Wire Mesh Machine Twist 3 Twist, 5cross
Power 22kw Speed 225m/h
Weight 14t After-sales Service Provided Engineers Available To Service Machinery Overseas
High Light

warping machine

,

large diameter hexagonal mesh machine

Leave a Message
Product Description

Automatic Three Twist Gabion Wire Mesh Weaving Machine Width 4.3m Wire




Quick Detail:


1.Gabion making Machine is the professional machine to produce inerratic gabion mesh ,the mesh can be
used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir
and other construction project.
2. it is the good material to prevent or control flood.




Description:


The LNWL series 3 gabion mesh machine can produce both double twisted mesh and three twisted mesh in
the same gabion mesh machine, it is very economy. A set of gabion making machine includes four main
parts: Mesh weaving machine, roll mesh machine, coiling spring machine, warping machine.




Advantages:


1. The LNWL-3 series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes; we can produce the machne as your size.
2. This new 3 series gabion mesh machines structure is simpleness, it can make the machine weaving mesh more easier.
3. The capability is stabilization, all the points of iunction have bearing to fix, the parts will hard-wearing, lengthen machine life.
4. The mesh that 3 series machine weave, the part of twist will be lnger that 2 series mchine, so when the mesh need edge curl that using the selvedge machine, it will going easily and smoothly.


This type machine is using spiral coil. And the twist could be double twisted and three twisted as
below picture.
Automatic Three Twist Gabion Wire Mesh Weaving Machine Width 4.3m 0 Automatic Three Twist Gabion Wire Mesh Weaving Machine Width 4.3m 1 Automatic Three Twist Gabion Wire Mesh Weaving Machine Width 4.3m 2
Pic 1:double twist mesh Pic 2: three twist mesh Pic 3: Gabion box application





Applications:


Gabion making Machine is the professional machine to produce inerratic gabion mesh ,the mesh can be
used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir
and other construction project, and it is the good material to prevent or control flood.




Specifications:



Style Mesh size Width Wire diamater Spindle Speed power of motor Theoretic output
(mm) (mm) (mm) (r/min) (kw) (m/h)
LNWL43-60-3 60X80 4300 1.6-2.8 25 22 165
LNWL43-80-3 80X100 1.6-3 195
LNWL43-100-3 100X120 225
LNWL43-120-3 120X150 1.6-3.2 20 255




Competitive Advantage:


1. JINLIDA company invented the first special equipment of double twisted wire netting making machine in
China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area
of gabion machine making for 15 years.
2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to
process, so the quality can be ensured.
3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare parts with cost
price if customer need.
