Automatic Hexagonal Wire Netting Machine 4mm / Spiral Coiling Machine

  • Automatic Hexagonal Wire Netting Machine 4mm / Spiral Coiling Machine
  • Automatic Hexagonal Wire Netting Machine 4mm / Spiral Coiling Machine
Place of Origin China
Brand Name Jinlida
Model Number 1200-4
Minimum Order Quantity 1
Price Competitive price
Packaging Details Nude packing
Delivery Time 50 days
Payment Terms L/C,T/T
Supply Ability 200 sets/a year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Automatic Max Wire Diameter 4mm
Material Spiral Coiling Power 1.5kw
Name Spring Coiling Machine Max Length 1200mm
High Light

warping machine

,

large diameter hexagonal mesh machine
Leave a Message
Product Description

Automatic Hexagonal Wire Netting Machine 4mm / Spiral Coiling Machine


Quick Detail:

   1. Quantity of spring bars: 4
   2. Rotational speed of spring bar: 450r/min
   3. Max length of spring coil: 1200mm
   4. Layer of spring coil :=> 4
   5. Max galvanized wire diameter: 4mm

Description:

      Type 1200-4 Spring Coiling Machine is assembled with LNWL-2 heavy duty hexagonal wire mesh machine
(gabion mesh making machine). The machine is equipped by four pieces of wire coiling bars, which can
rotate in synchrony by to-and-fro way for layers of wire-spiral-coiling, to increase the length of wire spiral
and to reduce the time of wire spiral changing during twisting to increase mesh-twisting efficiency.
     This machine, after changing the preset exchange gears, can meet the wire-spiral-coiling function for different diameter of wires.
     It has 4 pole spring, and these 4 pole spring can rotate at the same time when machine working and roll many levels to improve the efficiency. This kind of machine can also fit for different wire diameter.

  Automatic Hexagonal Wire Netting Machine 4mm / Spiral Coiling Machine 0

Specifications:


Quantity of spring bars 4 or 6 Rotational speed of spring bar 450r/min
Max length of spring coil 1200mm Layer of spring coil ≥4
Max galvanized wire diameter 4mm Max PVC wire diameter ≥5mm
Motor power 1.5kw Overall size  2200x90x1500mm

     1. Quantity of spring bars: 4
     2. Rotational speed of spring bar: 450r/min
     3. Max length of spring coil: 1200mm
     4. Layer of spring coil :=> 4
     5. Max galvanized wire diameter: 4mm
     6. Max PVC wire diameter :=> 5
     7. Motor power: 1.5kw
     8. Overall size: 2200x90x1500mm

Competitive Advantages:

     1. Jinlida company invented the first special equipment of double twisted wire netting making machine in
China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this
area of gabion machine making for 15 years.

     2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to
process, so the quality can be ensured.

     3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare
parts with cost price if customer need.
