Gabion Box Machine
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| High Light | gabion mesh machine,coiling spring machine |
||
|---|---|---|---|
Product Description
Gabion Box Machine
Quick Detail:
1. New type double rack drive gabion machine
2.High efficiency: theoretic output=4.25m/min
3. PLC control system touch screen(Option)
Descrition:
Gabion machine JINLIDA brand
1. Invented first double twist gabion machine in China
2. Apply for national patents, number is ZL99229381.2 and ZL00267066.5
3. SGS,TUV certificate
Gabion machine
JINLIDA series machine is designed to make hexagonal wire mesh of various widths and mesh sizes.
We have 15 years export experience establishing trade with more than 30 countries, and ,
DEACERO, NOVA-S a.s.& DKG and TFS HOLDINGS are our long-standing relationship customers.
Advantages:
1. New type double rack drive gabion machine
2.High efficiency: theoretic output=4.25m/min
3. PLC control system touch screen(Option)
4. Infrared ray safety(Option)
5. Automatic stop system (Option)
6.Automatic oil system
7. The equipment is satisfied with normal wire netting machine's requipment, and also can meet weaving large diameter hexagonal mesh's demand.
8. The design is innovation in China, it can weave the wire 4.0mm easily and speed as normal wire diameter.
Pic 1 Mesh Weaving Machine
Specifications:
| Style | Mesh size | Width | Wire diamater | Spindle Speed | Twist | power of motor | Theoretic output |
| (mm) | (mm) | (mm) | (r/min) | (r ) | (kw) | (m/h) | |
| LNWL23-60-2ZX | 60X80 | 2300 | 1.6-3.2 | 25 | 3 | 11 | 165 |
| LNWL23-80-2ZX | 80X100 | 1.6-4.0 | 3 | 195 | |||
| LNWL23-100-2ZX | 100X120 | 1.6-4.0 | 3 | 225 | |||
| LNWL23-120-2ZX | 120X150 | 1.6-4.2 | 20 | 3 | 255 | ||
| LNWL33-60-2ZX | 60X80 | 3300 | 1.6-3.2 | 25 | 3 | 15 | 165 |
| LNWL33-80-2ZX | 80X100 | 1.6-4.0 | 3 | 195 | |||
| LNWL33-100-2ZX | 100X120 | 1.6-4.0 | 3 | 225 | |||
| LNWL33-120-2ZX | 120X150 | 1.6-4.2 | 20 | 3 | 255 | ||
| LNWL43-60-2ZX | 60X80 | 4300 | 1.6-3.2 | 25 | 3 | 22 | 165 |
| LNWL43-80-2ZX | 80X100 | 1.6-4.0 | 3 | 195 | |||
| LNWL43-100-2ZX | 100X120 | 1.6-4.0 | 3 | 225 | |||
| LNWL43-120-2ZX | 120X150 | 1.6-4.2 | 20 | 3 | 255 | ||
| LNWL43-60-3ZX | 60X80 | 1.6-3.2 | 25 | 5 | 165 | ||
| LNWL43-80-3ZX | 80X100 | 1.6-4.0 | 5 | 195 | |||
| LNWL43-100-3ZX | 100X120 | 1.6-4.0 | 5 | 225 | |||
| LNWL43-120-3ZX | 120X150 | 1.6-4.2 | 20 | 5 | 255 |
Pic 2&3 Wire tension device&Netting winding machine
Pic 4 Spring coiling machine
JINLIDA Series Prduction Line
Competitive Advantage:
1. All the parts of netting sheet cutting machine are processed by our own factory, no parts were send to
outside to process, so the quality can be ensured.
2. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare parts with cost
price if customer need.
