Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh

  • Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh
  • Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh
  • Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh
Place of Origin China
Brand Name JINLIDA
Model Number LNWL4
Minimum Order Quantity 1
Price Competitive price
Packaging Details Nude packing
Delivery Time 50 days
Payment Terms L/C,T/T
Supply Ability 200 sets/a year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Hexagonal Mesh Machine Mesh Size 80x120mm
Mesh Width 2300mm Wire Diameter 2.6mm
Speed 195m/h Application Building
High Light

wire mesh making machine

,

crimped wire mesh machine
Leave a Message
Product Description

Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh



Quick Detail:



     The gabion box machine is the professional equipment that produces hexagonal mesh, its product is widely used in petroleum, building, farming and chemical engineering industry, keep warm piping and other piping, still be applicable to the river embankment protection, coast to manage, and the assisting of tunnel engineering and breakwater establish the etc.



Description

Overall Size 5850×1600 ×2300mm Mesh Size 80×120mm
Power 15kw Weight 8000kg
Mesh Width 2300mm Wire Diameter 2.6mm
Automatic oil system
PLC control system touch screen(option)
Automatic stop system(option)
specialized pressing device(option)
Infrared ray safety protection device(option)


     *PLC touch screen control: easy operation and protect motor
      *Automatic stop system (option): If coiling wires are ran out,the machine will stop automatically
      *Infrared ray safety protection system (option): ensure safety
     *Automatic oil system(option): automatic centralized grease lubrication



     A set of gabion mesh machine is composed of hexagonal wire mesh machine,wire tension device, netting winding machine and spring coiling machine.



Pic 1 Mesh Weaving Machine

Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh 0



Specifications:

Style Mesh size Width Wire diamater Spindle Speed power of motor Theoretic output
(mm) (mm) (mm) (r/min) (kw) (m/h)
LNWL23-60-4 60X80 2300 1.6-3 25 11 165
LNWL23-80-4 80X100 1.6-3 195
LNWL23-100-4 100X120 1.6-3.2 225
LNWL23-120-4 120X150 1.6-3.5 20 255
LNWL33-60-4 60X80 3300 1.6-2.8 25 15 165
LNWL33-80-4 80X100 1.6-3 195
LNWL33-100-4 100X120 1.6-3.2 225
LNWL33-120-4 120X150 1.6-3.5 20 255
LNWL43-60-4 60X80 4300 1.6-2.8 25 22 165
LNWL43-80-4 80X100 1.6-3 195
LNWL43-100-4 100X120 225
LNWL43-120-4 120X150 1.6-3.2 20 255



Pic 2&3 Wire tension device&Netting winding machine

 Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh 1



 Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh 2



Pic 4 Spring coiling machine

Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh 3



Picture 5 Packing

     A set of gabion machine will be loaded to one 40' container, it is nude packing  and will use wire to  fix the machines in the container, make sure it is safe on passage.

Automatic Hexagonal Mesh Machine 2300mm Wire Netting 80x120mm Gabion Mesh 4



JINLIDA Series Prduction Line

No. Name QTY
Standard Machine
1 Hexagonal mesh machine 1unit
2 6 bars spring coiling machine 1unit
3 Wire tension device 1unit
4 Mesh winding machine 1unit
Production line machine
5 Mesh straightening machine 1unit
6 Mesh cutting machine 1unit
7 Mesh conveying machine 1unit
8 Edge banding machine 2 units
9 Wire pay-off system 1unit
10 Gabion packing machine 1unit
11 Wire straightening and cutting machine 1unit





Competitive Advantage:

     1. Jinlida committed to making gabion mesh making machine, gabion production line for 24 years.



     2. Every part of gabion mesh machine is high quality,they are assembled by skilled workers who have years of experience.



     3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
