Galvanized Double Twist Gabion Mesh Machine 22kw 120*150mm, High Efficiency
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Gabion Mesh Machine | Power | 22kw |
|---|---|---|---|
| Twisting Number | 2 Twist,3 Cross | Type | Fully Automatic |
| High Light | gabion mesh machine,coiling spring machine |
||
Product Description
Custom Heavily Galvanized Gabion Mesh Packing Machine , High Efficiency
Quick Detail:
1.The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh
sizes.
2.The possible coatings are heavily galvanized and zinc.
3.For high corrosion resistance, zinc and PVC coated wire is available.
Description:
1.PLC control system touch screen.
2.If coiling wires are ran out, the machine will stop automatically.
3.Automatic oil system.
Specifications:
| Style | Mesh size | Width | Wire diamater | Spindle Speed | Twist | power of motor | Theoretic output |
| (mm) | (mm) | (mm) | (r/min) | (r ) | (kw) | (m/h) | |
| LNWL43-60-2ZX | 60X80 | 4300 | 1.6-3.2 | 25 | 3 | 22 | 165 |
| LNWL43-80-2ZX | 80X100 | 1.6-4.0 | 3 | 195 | |||
| LNWL43-100-2ZX | 100X120 | 1.6-4.0 | 3 | 225 | |||
| LNWL43-120-2ZX | 120X150 | 1.6-4.2 | 20 | 3 | 255 | ||
| LNWL43-60-3ZX | 60X80 | 4300 | 1.6-3.2 | 25 | 5 | 22 | 165 |
| LNWL43-80-3ZX | 80X100 | 1.6-4.0 | 5 | 195 | |||
| LNWL43-100-3ZX | 100X120 | 1.6-4.0 | 5 | 225 | |||
| LNWL43-120-3ZX | 120X150 | 1.6-4.2 | 20 | 5 | 255 |
A Set Of Gabion Machine Including Below Machines:
1. Main Machine
2. Wire tension device
3.Netting winding machine
4. Spring coiling machine
Competitive Advantage:
1. Jinlida company invented the first special equipment of double twisted wire netting making machine in
China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area
of g abion machine making for 15 years.
2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to
process, so the quality can be ensured.
3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare parts with cost
price if customer need.
