4m Galfan Coated Wire Automatic Gabion Mesh Machine 3.0mm - 3.2mm Wire

Name: 4m Galfan Coated Wire Automatic Gabion Mesh Machine 3.0mm - 3.2mm Wire
Brand: Jiangyin Jinlida Light Industry Machinery Co.,Ltd
SKU: LNWL4
Price: 23,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Jinlida

Certification: CE

Model Number: LNWL4

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Competitive price

Packaging Details: Nude packing

Delivery Time: 50 days

Payment Terms: L/C,T/T

Supply Ability: 200 sets/a year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                gabion mesh machine, Gabion Box Machine, automatic gabion mesh machine


Product Name:	Gabion Machine	Wire Diameter:	3.0-3.2mm
Mesh Width:	4m	Mesh Size:	100*120mm
Theoretic Output:	225m/h	Application:	Galfan Gabion Basket

Product Name:	Gabion Machine
Wire Diameter:	3.0-3.2mm
Mesh Width:	4m
Mesh Size:	100*120mm
Theoretic Output:	225m/h
Application:	Galfan Gabion Basket

4m Galfan Coated Wire Automatic Gabion Mesh Machine 3.0mm - 3.2mm Wire

4m Galfan Coated Wire Automatic Gabion Mesh Machine , Mesh Dia. 3.0mm - 3.2mm

Quick Detail:

Style	Size	Width	Diameter	Spindle Speed	Power of Motor	Theoretic Output
Style	(mm)	(mm)	(mm)	(r/min)	(kw)	(m/h)
LNWL43-60-4	60×80	4300	1.6-3.2	25	22	165
LNWL43-80-4	80×100		1.6-4.0			195
LNWL43-100-4	100×120		1.6-4.0			225
LNWL43-120-4	120×150		1.6-4.2	20		255

Application

Gabion Mesh Machine is the professional machine to produce inerratic gabion mesh, the mesh can be

used to produce coop, and is widely used as protect and sustain bank, hillside, road and bridge, reservoir

and other construction project, and it is the good material to prevent or control flood.

4m Galfan Coated Wire Automatic Gabion Mesh Machine 3.0mm - 3.2mm Wire 0

4m Galfan Coated Wire Automatic Gabion Mesh Machine 3.0mm - 3.2mm Wire 1

4m Galfan Coated Wire Automatic Gabion Mesh Machine 3.0mm - 3.2mm Wire 2

Competitive Advantage:

1. We have persevered in this area of gabion mesh machine for 20 years.Jinlida invented the first special equipment of double twist wire netting machine in China

2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to

process, so the quality can be ensured.

3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange

our technician to helpinstall the machines in your country, and also could supply all the spare parts with

cost price if customer need.
