Fullt Automatic 15Kw Gabion Hexagonal Mesh Machine With Zinc And PVC Galfan Coated
Contact me for free samples and coupons.
Wechat: 0086 18588475571
If you have any concern, we provide 24-hour online help.x
|After-sales Service Provided||Engineers Available To Service Machinery Overseas||Warranty||1 Year|
|Type||Fully Automatic||Color||Engineers Available To Service Machinery Overseas|
|Material||Zinc And PVC Galfan Coated||Name||Gabion Mesh Machine|
wire mesh making machine,
crimped wire mesh machine
15Kw Gabion Hexagonal Mesh Machine With Zinc And PVC Galfan Coated
1. Mesh sizes: 100X120mm
2. twist: double twist
3. Max. netting width: 3300mm
4. Max. galvanized wire diameter: 3.2mm
5. Max PVC wire diameter: 4.2mm
6. Spindle Speed:25r/min
7. Power: 15Kw
8. Size: 7200 x 1400 x 2400mm
9. Weight: 15MT
10. Theoretic output: 225m/hr
11. Automatic stop system (option): when the coiling finished or wire broken, the machine will stop
12. Infrared ray safety protection system (option)
13. Automatic oil system
Gabion Machine widely used in oil, construction, raising, chemical industry warming piping and etc. It is also
used in fence, apartment and greening. The hexagonal wire netting can be used in protect sea wall, hillside,
road, bridge and civil engineering. It is one of the best against flooding material.
The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh
sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC
coated wire is available.
1. Jinlida company invented the first special equipment of double twisted wire netting making machine in
China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area
of gabion machine making for 15 years.
2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to
process, so the quality can be ensured.
3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare parts with cost
price if customer need.
