Custom 3300mm Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire

  • Custom 3300mm Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire
  • Custom 3300mm Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire
  • Custom 3300mm Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire
  • Custom 3300mm Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire
  • Custom 3300mm Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire
Place of Origin China
Brand Name Jinlida
Model Number LNWL33-70-2
Minimum Order Quantity 1
Price Competitive price
Packaging Details Nude packing
Delivery Time 50 days
Payment Terms L/C,T/T
Supply Ability 200 sets/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type Automatic Weight 15t
Warranty 1 Year Mesh Width 3300mm
High Light

wire mesh making machine

,

crimped wire mesh machine
Leave a Message
Product Description

Custom Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire





Quick Detail:



1. High efficiency and stability

2. Low noise

3. Automatic Oil System

4. Automatic stop system (option): when the coiling finished or wire broken, the machine will stop automatically

5. Infrared ray safety protection system (option)



Description:



We can manufacture gabion machine according to customer request.

The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC, galfan coated wire is available.



Picture For Gabion Machine Working



 Custom 3300mm Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire 0





Gabion Application



 Gabion Machine widely used in oil, construction, raising, chemical industry warming piping and etc. It is also

used in fence, apartment and greening. The hexagonal wire netting can be used in protect sea wall, hillside,

road, bridge and civil engineering. It is one of the best against flooding material.

The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh

sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC

coated wire is available.

Custom 3300mm Automatic Hexagonal Gabion Mesh Machine , PVC Coated Wire 1



Specifications:



Style Mesh size Width Wire diamater Spindle Speed power of motor Theoretic output
(mm) (mm) (mm) (r/min) (kw) (m/h)
LNWL23-60-2 60X80 2300 1.6-3 25 11 165
LNWL23-80-2 80X100 1.6-3 195
LNWL23-100-2 100X120 1.6-3.2 225
LNWL23-120-2 120X150 1.6-3.5 20 255
LNWL33-60-2 60X80 3300 1.6-2.8 25 15 165
LNWL33-80-2 80X100 1.6-3 195
LNWL33-100-2 100X120 1.6-3.2 225
LNWL33-120-2 120X150 1.6-3.5 20 255
LNWL43-60-2 60X80 4300 1.6-2.8 25 22 165
LNWL43-80-2 80X100 1.6-3 195
LNWL43-100-2 100X120 225
LNWL43-120-2 120X150 1.6-3.2 20 255
