100x120mm Mesh Size Automatic Oil System 4300mm Gabion Machine

  • 100x120mm Mesh Size Automatic Oil System 4300mm Gabion Machine
  • 100x120mm Mesh Size Automatic Oil System 4300mm Gabion Machine
  • 100x120mm Mesh Size Automatic Oil System 4300mm Gabion Machine
  • 100x120mm Mesh Size Automatic Oil System 4300mm Gabion Machine
  • 100x120mm Mesh Size Automatic Oil System 4300mm Gabion Machine
Place of Origin China
Brand Name Jinlida
Certification CE, ISO
Model Number LNWL4
Minimum Order Quantity 1 set
Packaging Details Nude packing and will be fixed in the container by iron wire
Delivery Time 45 days
Supply Ability 200 sets/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Gabion Machine Mesh Size 100x120mm
Mesh Width 4300mm Device Automatic Oil System
High Light

coiling spring machine

,

Gabion Box Machine
Leave a Message
Product Description



Adjustable 4300mm Gabion Machine 100x120mm Mesh Size with Automatic Oil System



Quick Details



     The weaving mesh speed of LNWL4 adds to 60 moves per minute, in this way, efficiency improves one third of old machines.


Specifications



Style Mesh Size Width Wire Diameter Spindle Speed Power of Motor Theoretic Output
(mm) (mm) (mm) (r/min) (kw) (m/h)
LNWL4-60 60×80 4300 1.6-3.2 25 22 165
LNWL4-80 80×100 1.6-4.0 195
LNWL4-100 100×120 1.6-4.0 225
LNWL4-120 120×150 1.6-4.2 20 255



 Description:



     1. The design deletes the adjustment device, which set between rack and rubbing frame on old machines, makes the 4h series machine long service life, reliable operation, energy efficient and easy to maintain and repair.


     2. It can weave 3.2mm wire mesh easily like normal machine weave 2.4mm wire mesh, and speed is also quickly as normal style.



100x120mm Mesh Size Automatic Oil System 4300mm Gabion Machine 0    100x120mm Mesh Size Automatic Oil System 4300mm Gabion Machine 1



Advantages



    1. Its product is widely used in petroleum, building, farming and chemical engineering industry, keep warm piping and other piping.



    2. Jinlida has rich experience and professional skills to meet your needs and satisfy your requirements.



    3. It has the characteristics of moving steadily, low noise, high potency.



FAQ



    Q. What is your terms of packing?
    A: Nude packing and will be fixed in the 40'container by iron wire.



    Q: What is your terms of payment ?/ About payment

    A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos and videos of the products and packages before you pay the balance.
