Gabion Energy Saving Machine
1. Mesh sizes: 100x120mm
2. twist: double twist
3. Max. netting width: 2300mm
4. Max. galvanized wire diameter: 1.6-3.2mm
5. Max PVC wire diameter: 4.2mm
6. Spindle Speed:25r/min
7. Power: 11Kw
8. Weight: 15MT
9. Theoretic output: 225m/hr
10. Automatic stop system (option): when the coiling finished or wire broken, the machine will stop automatically
11. Infrared ray safety protection system (option)
12. Automatic oil system
The gabion machine can be added Automatic stop system and Infrared ray safety protection system if customers need.
The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh
sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC
coated wire is available
Gabion Machine Packing
A set of gabion machine will be loaded to one 40' container, it is nude packing and will use wire to fix the machines in the container, make sure it is safe on passage.
1. JINLIDA company invented the first special equipment of double twisted wire netting making machine in
China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area
of gabion machine making for 15 years.
2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to
process, so the quality can be ensured.
3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare parts with cost
price if customer need.
