4.5m Gabion Netting Sheet Wire Mesh Cutting Machine

Place of Origin China
Brand Name Jinlida
Certification CE, ISO
Model Number QWJ

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Mesh Width 4.5m Motor 7.5kw
Max Wire Diameter 4.0mm Application Gabion Production Line
High Light

4.5m Wire Mesh Cutting Machine

,

4.5m netting sheet Cutting Machine

,

gabion netting sheet Cutting Machine

Leave a Message
Product Description

4.5m Mesh Cutting Machine Automatic Cut Mesh Sheet for Gabion Production Line



Mesh cutting machine  is the necessary equipment of the hexagonal wire mesh production line.



Brief Introduction

The mesh shearing machine is controlled with PLC control system.You can set the time of electromagnet, number of mesh, speed of mesh conveying roller and length of mesh conveying.



Specifications

Max wire diameter 4.0mm Mesh width 4.5m
Shearing angle

1°30'

Certification CE, ISO
Power 7.5kw Warranty 1 year
Spindle speed 1460r/min Dimension 5400mm*1970*mm1400mm
Usage gabion production line MOQ 1 unit
Model Number QWJ-100 Weight 6000kg
Delivery time 40 days Port Shanghai



Features

1. The netting sheet cutting machine includes overall frame, fixed tool apron, shiftable tool rest, blade clearance adjustment device, numerical controls and position encoder.

2. Mesh straightening and mesh conveying adopt full automatic servo motor for dead length, easy to operate.And the cutting is clear and beautiful.

3. The mesh shearing machine is controlled with PLC control system.You can set the time of electromagnet, number of mesh, speed of mesh conveying roller and length of mesh conveying.

4.5m Gabion  Netting Sheet Wire Mesh Cutting Machine 0



Packing & Delivery

Packing Details: Nude packing and will be fixed in the 40'container by iron wire,make sure it is safe on passage.

Lead Time: 40 days



Service

1.OEM Manufacturing welcome: Product, Package...
2. We will reply you for your inquiry in 24 hours.
3. After sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.



Advantages

1.All the parts of gabion mesh machine are produced by our Jinlida,no parts were sending outside to produce,so we can guarantee the quality.

2.We provide12months warranty to help install the machines in your country,and also can supply all the spare parts at cost price if customers need.

3.We offer fine quality, competitive prices,prompt delivery and a satisfying service.



FAQ



Q1. What is your terms of packing?
A: Generally, we pack our goods in the container.



Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.



Q3. What is your terms of delivery?
A: FOB, CFR, CIF.
