Double Rack Drive Automatic Oil Heavy Duty Gabion Machine 120x150mm Mesh for Road and Bridge

Double Rack Drive Automatic Oil Heavy Duty Gabion Machine 120x150mm Mesh for Road and Bridge

  • High Light

    Double Twist wire straightener and cutter

    ,

    Double Twist wire straightening machine

    ,

    120x150mm wire straightener and cutter

  • Name
    Gabion Machine
  • Mesh Width
    4300mm
  • Mesh Size
    120x150mm
  • Wire Diameter
    1.6-3.2mm
  • Theoretic Output
    255m/h
  • Application
    Road And Bridge
  • Place of Origin
    Jiangsu,China
  • Brand Name
    Jinlida
  • Certification
    CE
  • Model Number
    LNWL4
  • Minimum Order Quantity
    one set
  • Packaging Details
    Nude packing and will be fixed in the 40'container by iron wire
  • Delivery Time
    40 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    300 Set/Sets per Year

Double Rack Drive Automatic Oil Heavy Duty Gabion Machine 120x150mm Mesh for Road and Bridge

Double Rack Drive Automatic Oil Heavy Duty Gabion Machine 120x150mm Mesh for Road and Bridge



Quick Details

Wire Diameter(mm): 1.6-4mm

Condition: New

Machine Type: Gabion Mesh Making Machine

Video outgoing-inspection: Provided

Warranty of core cpmponents: 1 Year

Core Components: PLC,Engine,Bearing,Gear,Pump

Power: 22kw

Mesh Size: 120*150mm

Theoretic Output: 255m/h





Packaging & Delivery

Packaging Details:Nude Packing and will be fixed in the 40 container by iron wire.

Port:Shanghai Port

Double Rack Drive Automatic Oil Heavy Duty Gabion Machine 120x150mm Mesh for Road and Bridge 0



Gabion Application

The product has widely purpose,with its good corrosion resistance and oxidation resistance,serves well as strengthen,protection and temperature keeping materials in the form of mesh container,stone cage,isolation wall,hillside,poultry fence in construction,petroleum,chemical,breeding.



Double Rack Drive Automatic Oil Heavy Duty Gabion Machine 120x150mm Mesh for Road and Bridge 1Double Rack Drive Automatic Oil Heavy Duty Gabion Machine 120x150mm Mesh for Road and Bridge 2



Detail Specification for all style of LNWL-4 Gabion Machine





-4H/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

五绞

five twist

拉网辊

Mesh roller

Ø

-4H

双绞捻网速度double twist knitting speed

-4HS

五绞捻网速度five twist knitting speed

60*85/ 28mm Ø180/ 5

















25 20
66*90/ 28mm Ø191/ 5

















25 20
70*90 /30mm Ø191/ 5 70*90/ 45mm Ø215/ 5 70*105/55mm Ø203.8/4 25 20
80*103/ 32mm Ø215 / 5 80*115/ 45mm Ø203/ 4 80*105/55mm Ø203/ 4 25 20
88*105/ 32mm Ø218/ 5 88*115/ 45mm Ø203/ 4 88*105/55mm Ø203/ 4 25 20
90*100/ 32mm Ø218/ 5 90*115/ 45mm Ø203/ 4 90*105/55mm Ø203/ 4 25 20
100*120/ 32mm Ø242/ 5 100*125 /45mm Ø217/ 4 100*115/55mm Ø217/ 4 25 20
110*140/ 32mm Ø219/ 4 110*126/ 45mm Ø218/ 4 110*116/55mm Ø218/ 4 25 20
120*140/ 32mm Ø219/ 4 120*140/ 45mm Ø295/ 5 120*130/55mm Ø295/ 4 25 20
Note:

1. -4H:不带伺服程序控制,-4HS:带伺服程序控制.

-4H: without servo program control, -4HS: with servo program control.

2. Ø拉网辊外径后面-4或-5为圆周上的拉网齿等分.

Mesh roller item: ‘4’ or ‘5’ means thorn nails equal parts number(how many nails rows of one roller ).

3. 网孔规格-32,-45,-55为网孔绞合部分的长度尺寸.

Double twist and five twist item: ‘32mm’, ‘45mm’, ‘55mm’ is twist length.

4. -4H型机设定每分钟理论生产速度为25个双绞网孔.

-4H machine theoretic output: 25 double twist mesh hole every minute.

5. -4HS型机设定每分钟理论生产速度为20个五绞网孔.

-4HS machine theoretic output: 20 five twist mesh hole every minute.



Advantages

1. Jinlida committed to making gabion mesh making machine, gabion production line for over 20 years.

2. The LNWL4 series mesh weaving machines have been designed to make gabion mesh of various widths and mesh sizes.

3. We offer fine quality, competitive prices,prompt delivery and a satisfying service.
