PLC Control Automatic Stop Gabion Mesh Machine 84*100mm 3x1x1m Gabion Box

  • PLC Control Automatic Stop Gabion Mesh Machine 84*100mm 3x1x1m Gabion Box
  • PLC Control Automatic Stop Gabion Mesh Machine 84*100mm 3x1x1m Gabion Box
  • PLC Control Automatic Stop Gabion Mesh Machine 84*100mm 3x1x1m Gabion Box
Place of Origin Jiangsu,China
Brand Name Jinlida
Certification CE, ISO9001
Model Number LNWL4
Minimum Order Quantity one set
Packaging Details Nude packing and will be fixed in the 40'container by iron wire
Delivery Time 40 days
Payment Terms T/T, L/C
Supply Ability 200 Set/Sets per Year
Product Details
Name Gabion Machine Mesh Width 4000mm
Mesh Size 84*100mm Wire Diameter 1.6mm-4.0mm
Theoretic Output 195m/h Application 3x1x1m Gabion Box
High Light

Gi Wire gabion mesh machine

,

Spiral Coil gabion mesh machine

,

SGS wire netting machine
Leave a Message
Product Description

PLC Control Automatic Stop Gabion Mesh Machine 84*100mm 3x1x1m Gabion Box



Quick Details



1. Adopted with automatic oil system.

2. PLC control system touch screen is available for the hexagonal wire mesh machine.

3. Automatic stop system saves much labor force.



Description



A set of gabion mesh machine is composed of hexagonal wire mesh machine, wire tension device, netting winding machine and spring coiling machine.



1. Machine uses big worm gear case, it reduces oil temperature to avoid worm burning hot. And the force of pulling mesh is greater.



2. It has low noise ,when something wrong it will give an alarm and automatically stop.



3. Adjustment of structure no longer be used in rack and big connecting rod, easier and more reliable to operate.



Specifications



Overall Size 7650×1600 ×2300mm Mesh Size 84×100mm
Power 22kw Weight 14000kg
Mesh Width 4000mm Max Wire Diameter 4.0mm
Automatic oil system
PLC control system touch screen(option)
Automatic stop system(option)
specialized pressing device(option)
Infrared ray safety protection device(option)
PLC Control Automatic Stop Gabion Mesh Machine 84*100mm 3x1x1m Gabion Box 0  PLC Control Automatic Stop Gabion Mesh Machine 84*100mm 3x1x1m Gabion Box 1  PLC Control Automatic Stop Gabion Mesh Machine 84*100mm 3x1x1m Gabion Box 2

Application



The gabion machine is the professional equipment that produces hexagonal mesh, its product is widely used in petroleum, building, farming and chemical engineering industry, keep warm piping and other piping, still be applicable to the river embankment the protection, coast to manage, and the assisting of tunnel engineering and breakwater establish the etc.



Advantages



1. Jinlida committed to making gabion mesh making machine, gabion production line for 22 years.



2. Every part of gabion mesh machine is high quality,they are assembled by skilled workers who have years of experience.





3. Precise design of complete machine, compact conformation, handiness and simplicity.
