100mmx120mm Zinc PVC Coated Wire Gabion Machine Corrosion Resistance

Product Details

Place of Origin: China

Brand Name: Jinlida

Model Number: LNWL4

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Competitive price

Packaging Details: Nude packing

Delivery Time: 50 days

Payment Terms: L/C,T/T

Supply Ability: 200 sets/ a year

Get Best Price
Highlight:

225m/h Wire Gabion Machine

,

Zinc Coated Wire Gabion Machine

,

Corrosion Resistance mesh knitting machine

Name:
Gabion Machine
Mesh Width:
4300mm
Mesh Size:
100×120mm
Wire Diameter:
1.6-4.0mm
Speed:
225m/h
Application:
Tunnel Engineering
Name:
Gabion Machine
Mesh Width:
4300mm
Mesh Size:
100×120mm
Wire Diameter:
1.6-4.0mm
Speed:
225m/h
Application:
Tunnel Engineering
100mmx120mm Zinc PVC Coated Wire Gabion Machine Corrosion Resistance

Hexagonal Mesh Gabion Machine 100mmx120mm For Zinc And PVC Coated Wire





Quick Detail:



     1. The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes.

     2. The possible coatings are heavily galvanized and zinc.

     3. For high corrosion resistance, zinc and PVC coated wire is available.



Parameter:

     1. Width single 4300mm
     2. Mesh size 100x120mm
     3. Material galvanized or PVC


Descrition:



     The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh

sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC

coated wire is available.



    Jinlida series machine is designed to make hexagonal wire mesh of various widths and mesh sizes.

We have 15 years export experience establishing trade with more than 30 countries, and ,

DEACERO, NOVA-S a.s.& DKG and TFS HOLDINGS are our long-standing relationship customers.



Gabion Application:



    Gabion Machine widely used in oil, construction, raising, chemical industry warming piping and etc. It is also

used in fence, apartment and greening. The hexagonal wire netting can be used in protect sea wall, hillside,

road, bridge and civil engineering. It is one of the best against flooding material.



Specifications:

-4H/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

五绞

five twist

拉网辊

Mesh roller

Ø

-4H

双绞捻网速度double twist knitting speed

-4HS

五绞捻网速度five twist knitting speed

60*85/ 28mm Ø180/ 5

















25 20
66*90/ 28mm Ø191/ 5

















25 20
70*90 /30mm Ø191/ 5 70*90/ 45mm Ø215/ 5 70*105/ 55mm Ø203.8/4 25 20
80*103/ 32mm Ø215 / 5 80*115/ 45mm Ø203/ 4 80*105/ 55mm Ø203/ 4 25 20
88*105/ 32mm Ø218/ 5 88*115/ 45mm Ø203/ 4 88*105/ 55mm Ø203/ 4 25 20
90*100/ 32mm Ø218/ 5 90*115/ 45mm Ø203/ 4 90*105/ 55mm Ø203/ 4 25 20
100*120/ 32mm Ø242/ 5 100*125 /45mm Ø217/ 4 100*115/ 55mm Ø217/ 4 25 20
110*140/ 32mm Ø219/ 4 110*126/ 45mm Ø218/ 4 110*116/ 55mm Ø218/ 4 25 20
120*140/ 32mm Ø219/ 4 120*140/ 45mm Ø295/ 5 120*130/ 55mm Ø295/ 4 25 20
Note:

1. -4H:不带伺服程序控制,-4HS:带伺服程序控制.

-4H: without servo program control, -4HS: with servo program control.

2. Ø拉网辊外径后面-4或-5为圆周上的拉网齿等分.

Mesh roller item: ‘4’ or ‘5’ means thorn nails equal parts number(how many nails rows of one roller ).

3. 网孔规格-32,-45,-55为网孔绞合部分的长度尺寸.

Double twist and five twist item: ‘32mm’, ‘45mm’, ‘55mm’ is twist length.

4. -4H型机设定每分钟理论生产速度为25个双绞网孔.

-4H machine theoretic output: 25 double twist mesh hole every minute.

5. -4HS型机设定每分钟理论生产速度为20个五绞网孔.

-4HS machine theoretic output: 20 five twist mesh hole every minute.





Picture for hexagonal mesh machine working



1. Mesh machine weaving mesh

 100mmx120mm  Zinc PVC Coated Wire Gabion Machine  Corrosion Resistance 0



2. Spring coiling machine working

100mmx120mm  Zinc PVC Coated Wire Gabion Machine  Corrosion Resistance 1



 3. Wire Pay Off System Working

100mmx120mm  Zinc PVC Coated Wire Gabion Machine  Corrosion Resistance 2



 Competitive Advantages:



     1. Jinlida company invented the first special equipment of double twisted wire netting making machine in

China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area

of g abion machine making for 15 years.



     2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to

process, so the quality can be ensured.



     3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
