Clockwise Spin Galvinised Gabion Machine Smooth Feeding

Place of Origin Jiangsu, China
Brand Name Jinlida
Certification CE, ISO9001
Model Number LNWL2
Minimum Order Quantity 1 set
Price competitive price
Packaging Details Nude packing and will be fixed in the container by iron wire.
Delivery Time 50 days
Payment Terms L/C, T/T
Supply Ability 200 sets per year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Name Gabion Mesh Machine Mesh Hole 106mm × 120 Mm
Mesh Width 4*1mm Power 22kw
Wire Diameter 4.0mm Application Sustain Bank
High Light

galvanised Gabion Machine


galvanised Gabion equipment


clockwise spin Gabion Machine

Leave a Message
Product Description


Galvanized 4.0 mm PVC Wire 4*1m Gabion Machine106*120mm Mesh for Sustain Bank


Brief Introduction:


     Gabion machine is also known as wire mesh machine, which is the professional machine to produce hexagonal wire netting.




      Packing Details: Nude packing and will be fixed in the container by iron wire.

      Lead Time: 50 days


Principle of Mechanics:


     Half gears spin clockwise and anticlockwise to weave mesh.



     1. Small specification mesh and thick wire, seine roller has to reinforce compressive stress to match the mesh.

     2. If coiling wires are ran out, the machine will stop automatically.

     3. Adopted with central automatic lubrication system, so as to make feeding guideway to have the good performance for little resistance, little friction, good lubrication and long life etc.



Overall Size 7850×1600×2300mm Mesh Size 106mm×120mm
Power 30kw Weight 14t
Mesh Width 4*1m Max Wire Diameter 4.0mm
Automatic oil system
PLC control system touch screen(option)
Automatic stop system(option)
Specialized pressing device(option)
Infrared ray safety protection device(option)


Clockwise Spin Galvinised Gabion Machine Smooth Feeding 0 Clockwise Spin Galvinised Gabion Machine Smooth Feeding 1 Clockwise Spin Galvinised Gabion Machine Smooth Feeding 2 Clockwise Spin Galvinised Gabion Machine Smooth Feeding 3


​ ​ ​
Competitive Advantages:

     1. Precise design of complete machine, compact conformation, handiness and simplicity.

     2. All the parts of gabion mesh machine are produced by our Jinlida, no parts were sending outside to produce, so we can guarantee the quality.

     3. Jinlida has rich experience and professional skills to meet your needs and satisfy your requirements.

     * In order to quote you right price, please supply us more of your specification requirements such as: mesh size, mesh width, wire diameter and so on.
