Product Details
Place of Origin: China
Brand Name: Jinlida
Certification: CE ISO
Model Number: 1200-6
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Competitive price
Packaging Details: Nude packing
Delivery Time: 50 days
Payment Terms: L/C,T/T
Supply Ability: 400 sets/a year
Name: |
6 Bars Spring Coiling Machine |
Speed: |
450r/min |
Max Length Of Spring Coil: |
120mm |
Layer Of Spring Coil: |
4 |
Motor: |
3kw |
Usage: |
Part Of Gabion Machine |
Name: |
6 Bars Spring Coiling Machine |
Speed: |
450r/min |
Max Length Of Spring Coil: |
120mm |
Layer Of Spring Coil: |
4 |
Motor: |
3kw |
Usage: |
Part Of Gabion Machine |
1.5kw Heavy Duty Gabion Mesh Making Machine / Automatic Spring Coiling Machine
Quick Detail:
| Quantity of spring bars | 6 | Rotational speed of spring bar | 450r/min |
| Max length of spring coil | 1200mm | Layer of spring coil | ≥4 |
| Max galvanized wire diameter | 4mm | Max PVC wire diameter | ≥5mm |
| Motor power | 1.5kw | Overall size | 2200x90x1500mm |
Description:
Type 1200-6 Spring Coiling Machine is assembled with hexagonal wire mesh machine
(gabion mesh making machine). The machine is equipped by four pieces of wire coiling bars, which can
rotate in synchrony by to-and-fro way for layers of wire-spiral coiling, to increase the length of wire spiral
and to reduce the time of wire spiral changing during twisting to increase mesh-twisting efficiency. This
machine, after changing the preset exchange gears, can meet the wire-spiral-coiling function for different
diameter of wires.
Application
A part of gabion mesh machine.
A set of gabion mesh machine includes: main machine, wire tension device, 6 bars spring coiling machine and mesh winding machine.
Competitive Advantages:
1. Jinlida is the professional manufacturer of the hexagonal wire mesh machine, and our factory is initiative for gabion mesh machine in China.
2. Every part of gabion mesh machine is high quality, they are assembled by skilled workers who have years of experience.
3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country,and also could supply all the spare parts with cost
price if customer need.
