450r/Min Spiral Coil Hexagonal Mesh Machine Heavy Duty

Place of Origin China
Brand Name Jinlida
Certification SGS,CE
Minimum Order Quantity 1 set
Price Competitive price
Packaging Details Nude packing
Delivery Time 50 days
Payment Terms L/C,T/T
Supply Ability 400 sets/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Name Sprial Coil Machine Application Machine For Gabion Mesh
Type Automatic
High Light

spiral coil Hexagonal Mesh Machine


450r/min Hexagonal Mesh Machine


spiral coil wire mesh machine

Leave a Message
Product Description

High Efficiency Metal Hexagonal Mesh Machine For Making Gabion Mesh



Quick Detail:


1. Quantity of spring bars: 6

2. Rotational speed of spring bar: 450r/min

3. Max length of spring coil: 1200mm

4. Layer of spring coil :=> 4

5. Max galvanized wire diameter: 4mm




     Type 1200-6 Spring Coiling Machine is assembled with LNWL-4 heavy duty hexagonal wire mesh machine

 (gabion mesh making machine). The machine is equipped by six pieces of wire coiling bars, which can

rotate in synchrony by to-and-fro way for layers of wire-spiralcoiling, to increase the length of wire spiral

and to reduce the time of wire spiral changing during twisting to increase mesh-twisting efficiency.

    This machine, after changing the preset exchange gears, can meet the wire-spiral-coiling function for different diameter of wires.


450r/Min Spiral Coil Hexagonal Mesh Machine Heavy Duty 0   450r/Min Spiral Coil Hexagonal Mesh Machine Heavy Duty 1



1. Quantity of spring bars: 6

2. Rotational speed of spring bar: 450r/min

3. Max length of spring coil: 1200mm

4. Layer of spring coil :=> 4

5. Max galvanized wire diameter: 4mm

6. Max PVC wire diameter :=> 5

7. Motor power: 1.5kw

8. Overall size: 2200x90x1500mm


Competitive Advantage:


1. Jinlidacompany invented the first special equipment of double twisted wire netting making machine in

China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area

of gabion machine making for 20 years.


2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to

process, so the quality can be ensured.


3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
