106*120mm Gabion Box Machine , 4.2mm Wire Mesh Making Machine

106*120mm Gabion Box Machine , 4.2mm Wire Mesh Making Machine

  • High Light

    4.2mm Gabion Box Machine


    4.2mm wire mesh making machine


    fences wire net making machine

  • Name
    Gabion Box Making Machine
  • Mesh Width
  • Mesh Size
  • Wire Diameter
  • Speed
  • Application
    Chemical Industrial
  • Place of Origin
  • Brand Name
  • Model Number
  • Minimum Order Quantity
  • Price
    Competitive price
  • Packaging Details
    Nude packing
  • Delivery Time
    50 days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    200 sets/a year

106*120mm Gabion Box Machine , 4.2mm Wire Mesh Making Machine

Custom 106*120mm Gabion Box Making Machine / Gabion Mesh Machine For Chemical Industrial



Quick Detail:


1.The gabion box machine is widely used in oil, construction, raising, chemical industry, warming piping and

etc. It is also used in fences, apartment and greening.

2.The hexagonal wire netting can be used in protect seawall, hillside, road, bridge and civil engineering.

3. It is one of the best against flooding materials.



1. PLC control system touch screen.

2. If coiling wires are ran out, the machine will stop automatically.

3. Automatic centralized grease lubrication.


The machine is supposed to be in continuous and smooth operation, saving much labour force.




Overall Size 7850×1600 ×2300mm Mesh Size 106×120mm
Power 22kw Weight 14000kg
Mesh Width 4300mm Max Wire Diameter 4.2mm
Automatic oil system
PLC control system touch screen(option)
Automatic stop system(option)
specialized pressing device(option)
Infrared ray safety protection device(option)

A set of gabion box machine includes four main parts: Mesh weaving machine, wire tension roller, mesh winding machine and 6 bars spring coiling mahcine.

106*120mm Gabion Box Machine , 4.2mm Wire Mesh Making Machine 0


Competitive Advantage:


1. Jinlida committed to making gabion mesh making machine, gabion production line for 20 years.


2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to

process, so the quality can be ensured.


3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
