2.5mm Wire Dia Gabion Box Machine For Seawall Protection

Name: 2.5mm Wire Dia Gabion Box Machine For Seawall Protection
Brand: Jiangyin Jinlida Light Industry Machinery Co.,Ltd
SKU: LNWL43-80-2
Price: 23,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: JIinlida

Model Number: LNWL43-80-2

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Competitive price

Packaging Details: Nude packing

Delivery Time: 50 days

Payment Terms: L/C,T/T

Supply Ability: 200 sets/a year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                automatic stop Gabion Box Machine, seawall protection Gabion Box Machine, 2.5mm  wire net making machine


Type:	Automatic PLC Control	Additional Device:	Automatic Stop System
Wire Diameter:	2.5mm

Type:	Automatic PLC Control
Additional Device:	Automatic Stop System
Wire Diameter:	2.5mm

2.5mm Wire Dia Gabion Box Machine For Seawall Protection

Roll Mesh Gabion Box Machine With Automatic Stop System / 2.5mm Wire Dia.

Quick Detail:

The machine max weaving width is 4m, it can weave one 4m mesh, also can weave one 1m and one 3m, two 2m mesh, four 1m mesh. And if customers need the machine that max width is 5m, we also can produce as your demands!

Specifications:

Style	Mesh Size	Width	Wire Diameter	Spindle Speed	Twist	Power of Motor	Theoretic Output
Style	(mm)	(mm)	(mm)	(r/min)	(r)	(kw)	(m/h)
LNWL43-60-2	60×80	4300	1.6-3.2	25	3	22	165
LNWL43-80-2	80×100		1.6-4.0				195
LNWL43-100-2	100×120		1.6-4.0				225
LNWL43-120-2	120×150		1.6-4.2	20			255
LNWL50-60-2	60×80	5000	1.6-3.2	25	3	30	165
LNWL50-80-2	80×100		1.6-4.0				195
LNWL50-100-2	100×120		1.6-4.0				225
LNWL50-120-2	120×150		1.6-4.2	20			255

2.5mm Wire Dia Gabion Box Machine For Seawall Protection 0

Gabion Box

2.5mm Wire Dia Gabion Box Machine For Seawall Protection 1

Application:

The gabion box machine is widely used in oil, construction, raising, chemical industry, warming piping and etc. It is also used in fence, apartment and greening. The hexagonal wire netting can be used in protect seawall, hillside, road, bridge and civil engineering. It is one of the best against flooding materials.

2.5mm Wire Dia Gabion Box Machine For Seawall Protection 2

Competitive Advantages:

1. Jinlida company invented the first special equipment of double twisted wire netting making machine in China (patent number: ZL99229381.2 and ZL00267066.5). And until now, we have persevered in this area of gabion machine making for 15 years.

2.Machine has the feature of rational design, simple structure, smooth running, excellent performance, reliable operation and convenient maintenance.
