195m/H Double Twist Gabion Production Line fencing applicaiton

Place of Origin China
Brand Name Jinlida
Certification TUV
Model Number LNWL4
Minimum Order Quantity 1
Price Competitive price
Packaging Details Nude packing
Delivery Time 40 days
Payment Terms L/C,T/T
Supply Ability 200 sets/a year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Gabion Mesh Machine Mesh Width 4300mm
Mesh Size 92*127mm Wire Diameter 1.6-4.0mm
Speed 195m/h Application Fencing
High Light

Double Twist Gabion Production Line

,

195m/h Gabion Production Line

,

195m/h Gabion making machine

Leave a Message
Product Description



Double Twist Automatic PLC Control Gabion Mesh Machine Infrared Ray Safety



Features:

1. No longer need to be adjusted after leaving factory.

2. PLC control system touch screen

3. Infrared ray safety(Option)

4. Automatic stop system (Option)



Description:

Gabion Mesh Making machine Jinlida brand

1. Invented first double twist gabion mesh making machine in China

2. PLC control system touch screen is available for the hexagonal wire mesh machine.

3. The weaving mesh speed of LNWL4 adds to 60 moves per minute, in this way, efficiency improves one third of old machines.



Pic 1 Mesh Making Machine



 195m/H Double Twist Gabion Production Line fencing applicaiton 0



195m/H Double Twist Gabion Production Line fencing applicaiton 1



Specifications:

-4H/

双绞

double twist

拉网辊

Mesh rollerØ

-4HS/

双绞

double twist

拉网辊

Mesh rollerØ

-4HS/

五绞

five twist

拉网辊

Mesh rollerØ

-4H

双绞捻网速度double twist knitting speed

-4HS

五绞捻网速度five twist knitting speed

60*85/ 28mm Ø180/ 5

















25 20
66*90/ 28mm Ø191/ 5

















25 20
70*90 /30mm Ø191/ 5 70*90/ 45mm Ø215/ 5 70*105/ 55mm Ø203.8/4 25 20
80*103/ 32mm Ø215 / 5 80*115/ 45mm Ø203/ 4 80*105/ 55mm Ø203/ 4 25 20
88*105/ 32mm Ø218/ 5 88*115/ 45mm Ø203/ 4 88*105/ 55mm Ø203/ 4 25 20
90*100/ 32mm Ø218/ 5 90*115/ 45mm Ø203/ 4 90*105/ 55mm Ø203/ 4 25 20
100*120/ 32mm Ø242/ 5 100*125 /45mm Ø217/ 4 100*115/ 55mm Ø217/ 4 25 20
110*140/ 32mm Ø219/ 4 110*126/ 45mm Ø218/ 4 110*116/ 55mm Ø218/ 4 25 20
120*140/ 32mm Ø219/ 4 120*140/ 45mm Ø295/ 5 120*130/ 55mm Ø295/ 4 25 20
Note:

1. -4H:不带伺服程序控制,-4HS:带伺服程序控制.

-4H: without servo program control, -4HS: with servo program control.

2. Ø拉网辊外径后面-4或-5为圆周上的拉网齿等分.

Mesh roller item: ‘4’ or ‘5’ means thorn nails equal parts number(how many nails rows of one roller ).

3. 网孔规格-32,-45,-55为网孔绞合部分的长度尺寸.

Double twist and five twist item: ‘32mm’, ‘45mm’, ‘55mm’ is twist length.

4. -4H型机设定每分钟理论生产速度为25个双绞网孔.

-4H machine theoretic output: 25 double twist mesh hole every minute.

5. -4HS型机设定每分钟理论生产速度为20个五绞网孔.

-4HS machine theoretic output: 20 five twist mesh hole every minute.





Pic 2&3 Wire tension device&Netting winding machine



 195m/H Double Twist Gabion Production Line fencing applicaiton 2 195m/H Double Twist Gabion Production Line fencing applicaiton 3

 Pic 4 Spring coiling machine

195m/H Double Twist Gabion Production Line fencing applicaiton 4



JINLIDA Series Prduction Line

195m/H Double Twist Gabion Production Line fencing applicaiton 5



Competitive Advantage:

 1. Our factory is the professional manufacturer of the hexagonal wire mesh machine, and our factory is initiative for gabion mesh machine in China.

 2. Jinlida has rich experience and professional skills to meet your needs and satisfy your requirements.

 3. We offer fine quality, competitive prices,prompt delivery and a satisfying service.
