Automatic High Efficiency 225m/h Hexagonal Wire Netting Machine 100*120mm Gabion Mesh

Product Details

Place of Origin: China

Brand Name: Jinlida

Model Number: LNWL4

Payment & Shipping Terms

Minimum Order Quantity: 1 SET

Packaging Details: Nude packing

Delivery Time: 50-60 days

Payment Terms: L/C T/T

Supply Ability: 200 sets/a year

Get Best Price
Highlight:

225m/h Hexagonal Mesh Machine

,

225m/h hexagonal wire netting machine

,

4.0mm hexagonal wire netting machine

Product Name:
Hexagonal Wire Mesh Machine
Mesh Width:
4300mm
Mesh Size:
100*120mm
Wire Diameter:
1.6-4.0mm
Speed:
225m/h
Application:
Green Guard Rail Netting
Product Name:
Hexagonal Wire Mesh Machine
Mesh Width:
4300mm
Mesh Size:
100*120mm
Wire Diameter:
1.6-4.0mm
Speed:
225m/h
Application:
Green Guard Rail Netting
Automatic High Efficiency 225m/h Hexagonal Wire Netting Machine 100*120mm Gabion Mesh

Automatic High Efficiency 225m/h Hexagonal Wire Netting Machine 100*120mm Gabion Mesh


Quick Detail:

1. Wire diameter:1.6-4.0mm
2. Speed:225m/h
3. Mesh width:3300mm (also can be 2300mm or 4300mm)
4. Power: 15kw


Description:

The LNWL4 series mesh weaving machines have been designed to make gabion mesh of various widths and mesh sizes.I

The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC, galfan coated wire is available.
We can manufacture gabion machine according to customer request.


Detail Specification for all style of LNWL4 Gabion Machine

-4H/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

五绞

five twist

拉网辊

Mesh roller

Ø

-4H

双绞捻网速度double twist knitting speed

-4HS

五绞捻网速度five twist knitting speed

60*85/ 28mmØ180/ 5

















2520
66*90/ 28mmØ191/ 5

















2520
70*90 /30mmØ191/ 570*90/ 45mmØ215/ 570*105/ 55mmØ203.8/42520
80*103/ 32mmØ215 / 580*115/ 45mmØ203/ 480*105/ 55mmØ203/ 42520
88*105/ 32mmØ218/ 588*115/ 45mmØ203/ 488*105/ 55mmØ203/ 42520
90*100/ 32mmØ218/ 590*115/ 45mmØ203/ 490*105/ 55mmØ203/ 42520
100*120/ 32mmØ242/ 5100*125 /45mmØ217/ 4100*115/ 55mmØ217/ 42520
110*140/ 32mmØ219/ 4110*126/ 45mmØ218/ 4110*116/ 55mmØ218/ 42520
120*140/ 32mmØ219/ 4120*140/ 45mmØ295/ 5120*130/ 55mmØ295/ 42520
Note:

1. -4H:不带伺服程序控制,-4HS:带伺服程序控制.
-4H: without servo program control, -4HS: with servo program control.

2. Ø拉网辊外径后面-4或-5为圆周上的拉网齿等分.
Mesh roller item: ‘4’ or ‘5’ means thorn nails equal parts number(how many nails rows of one roller ).

3. 网孔规格-32,-45,-55为网孔绞合部分的长度尺寸.
Double twist and five twist item: ‘32mm’, ‘45mm’, ‘55mm’ is twist length.

4. -4H型机设定每分钟理论生产速度为25个双绞网孔.
-4H machine theoretic output: 25 double twist mesh hole every minute.

5. -4HS型机设定每分钟理论生产速度为20个五绞网孔.
-4HS machine theoretic output: 20 five twist mesh hole every minute.


Application:
Gabion making machine is the professional machine to produce hexagonal mesh,the mesh can be used to produce coop,and is widely used as protect and sustain bank,hillside,road and bridge, reservoir and other construction project. And it is one of the best material against flood.
Automatic High Efficiency 225m/h Hexagonal Wire Netting Machine 100*120mm Gabion Mesh 0

Competitive Advantages:

1.All the parts of gabion mesh machine are produced by our Jinlida,no parts were sending outside to produce,so we can guarantee the quality.

2.We provide12months warranty to help install the machines in your country,and also can supply all the spare parts at cost price if customers need.

3.We offer fine quality, competitive prices,prompt delivery and a satisfying service.
