3300mm Hexagonal Wire Netting Equipment 195m/H For Highway Guardrail

Place of Origin China
Brand Name Jinlida
Model Number LNWL4
Minimum Order Quantity 1
Price Competitive price
Packaging Details Nude packing
Delivery Time 50 days
Payment Terms L/C,T/T
Supply Ability 200 sets/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Hexagonal Mesh Machine Mesh Width 3300mm
Mesh Size 88*120mm Wire Diameter 1.6-4.0mm
Speed 195m/h Application Highway Guard Rail Netting
High Light

3300mm hexagonal wire netting equipment

,

195m/h hexagonal wire netting equipment

,

gabion Hexagonal Mesh production line

Leave a Message
Product Description

Custom 3300mm Galvanized Wire Hexagonal Mesh Machine 3*1*1m Gabion Basket​





Quick Detail:

1.The mesh weaving machine is controlled by PLC control system.

2.The mesh weaving machine is designed by our Jinlida,and we have applied for patent.

3.All the parts of gabion mesh machine are processed by our own factory,no parts were sent outside to process,so the quality can be ensured.



Description:



The machine is supposed to be in continuous and smooth operation, saving much labour force.It has low noise and automatic stop system.If coiling wires are ran out,the machine will stop automatically.



1.The mesh weaving machine we made adopts PLC control system and automatic oil system.

2.It is the ideal machinery that weaves big signification,breadth portal arm,thick silk gabion mesh.

3.For high corrosion resistance,zinc and PVC,Galfan coated is available.



Picture For Gabion Machine Working

3300mm Hexagonal Wire Netting Equipment 195m/H For Highway Guardrail 0







Gabion Application



 Gabion Machine widely used in oil, construction, raising, chemical industry warming piping and etc. It is also

used in fence, apartment and greening. The hexagonal wire netting can be used in protect sea wall, hillside,

road, bridge and civil engineering. It is one of the best against flooding material.

The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh

sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC

coated wire is available.

3300mm Hexagonal Wire Netting Equipment 195m/H For Highway Guardrail 1



Specifications:

-4H/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

双绞

double twist

拉网辊

Mesh roller

Ø

-4HS/

五绞

five twist

拉网辊

Mesh roller

Ø

-4H

双绞捻网速度double twist knitting speed

-4HS

五绞捻网速度five twist knitting speed

60*85/ 28mm Ø180/ 5

















25 20
66*90/ 28mm Ø191/ 5

















25 20
70*90 /30mm Ø191/ 5 70*90/ 45mm Ø215/ 5 70*105/ 55mm Ø203.8/4 25 20
80*103/ 32mm Ø215 / 5 80*115/ 45mm Ø203/ 4 80*105/ 55mm Ø203/ 4 25 20
88*105/ 32mm Ø218/ 5 88*115/ 45mm Ø203/ 4 88*105/ 55mm Ø203/ 4 25 20
90*100/ 32mm Ø218/ 5 90*115/ 45mm Ø203/ 4 90*105/ 55mm Ø203/ 4 25 20
100*120/ 32mm Ø242/ 5 100*125 /45mm Ø217/ 4 100*115/ 55mm Ø217/ 4 25 20
110*140/ 32mm Ø219/ 4 110*126/ 45mm Ø218/ 4 110*116/ 55mm Ø218/ 4 25 20
120*140/ 32mm Ø219/ 4 120*140/ 45mm Ø295/ 5 120*130/ 55mm Ø295/ 4 25 20
Note:

1. -4H:不带伺服程序控制,-4HS:带伺服程序控制.

-4H: without servo program control, -4HS: with servo program control.

2. Ø拉网辊外径后面-4或-5为圆周上的拉网齿等分.

Mesh roller item: ‘4’ or ‘5’ means thorn nails equal parts number(how many nails rows of one roller ).

3. 网孔规格-32,-45,-55为网孔绞合部分的长度尺寸.

Double twist and five twist item: ‘32mm’, ‘45mm’, ‘55mm’ is twist length.

4. -4H型机设定每分钟理论生产速度为25个双绞网孔.

-4H machine theoretic output: 25 double twist mesh hole every minute.

5. -4HS型机设定每分钟理论生产速度为20个五绞网孔.

-4HS machine theoretic output: 20 five twist mesh hole every minute.



Advantages

1. Jinlida series machines are designed to make gabion mesh of various widths and mesh sizes, we can produce the machine as your size.

2. Excellent quality, reasonable price and first-class service.

3. Every part of gabion mesh machine is high quality,they are assembled by skilled workers who have years of experience.
