Chemical Gabion Mesh Machine 225m/H Gabion Box Production Line

Place of Origin China
Brand Name JINLIDA
Model Number LNWL4
Minimum Order Quantity 1
Price Competitive price
Packaging Details Nude packing
Delivery Time 50 days
Payment Terms L/C,T/T
Supply Ability 200 sets/a year
Product Details
Name Gabion Box Making Machine Mesh Width 4300mm
Mesh Size 106*120mm Wire Diameter 2.6-4.2mm
Speed 225m/h Application Chemical Industrial
High Light

Chemical Gabion Mesh Machine

,

225m/H Gabion Box Production Line

,

Touch Screen Gabion Box Production Line

Leave a Message
Product Description

Custom 106*120mm Gabion Box Making Machine / Gabion Mesh Machine For Chemical Industrial



The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC, galfan coated wire is available.We can manufacture gabion machine according to customer request.



  • Gabion mesh machine is specialization in production of hexagonal wire mesh.
  • The raw material: hot-dipped galvanized low carbon steel wire,Galfan wire, PVC coated wire.
  • Electric galvanized wire: Zinc rate 10g/m2 poor corrosion prevention
  • Hot -dipped galvanized low carbon steel wire: Zinc rate 300g/m2 strong corrosion prevention
  • Galfan wire(Zinc -5%Aluminum wire): corrosion prevention is three times of traditional galvanized wire.
  • PVC coated wire : having strong corrosion prevention and good fusion of color and environment.



Quick Detail:



1.The gabion box machine is widely used in oil, construction, raising, chemical industry, warming piping and

etc. It is also used in fence, apartment and greening.

2.The hexagonal wire netting can be used in protect seawall, hillside, road, bridge and civil engineering.

3. It is one of the best against flooding materials.



Description:

1. PLC control system touch screen.

2. If coiling wires are ran out, the machine will stop automatically.

3. Automatic centralized grease lubrication.



The machine is supposed to be in continuous and smooth operation, saving much labour force.



Specifications:



Overall Size 7850×1600 ×2300mm Mesh Size 106×120mm
Power 22kw Weight 14000kg
Mesh Width 4300mm Max Wire Diameter 4.2mm
Automatic oil system
PLC control system touch screen(option)
Automatic stop system(option)
specialized pressing device(option)
Infrared ray safety protection device(option)

A set of gabion box machine includes four main parts: Mesh weaving machine, wire tension roller, mesh winding machine and 6 bars spring coiling mahcine.

Chemical Gabion Mesh Machine 225m/H Gabion Box Production Line 0



Competitive Advantage:



1. Jinlida committed to making gabion mesh making machine, gabion production line for 20 years.



2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to

process, so the quality can be ensured.



3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
