Custom 106*120mm Gabion Box Making Machine / Gabion Mesh Machine For Chemical Industrial

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xName | Gabion Box Making Machine | Mesh Width | 4300mm |
---|---|---|---|
Mesh Size | 106*120mm | Wire Diameter | 2.6-4.2mm |
Speed | 225m/h | Application | Chemical Industrial |
High Light | Gabion Making Machine,mesh making machine |
Custom 106*120mm Gabion Box Making Machine / Gabion Mesh Machine For Chemical Industrial
Quick Detail:
1.The gabion box machine is widely used in oil, construction, raising, chemical industry, warming piping and
etc. It is also used in fence, apartment and greening.
2.The hexagonal wire netting can be used in protect seawall, hillside, road, bridge and civil engineering.
3. It is one of the best against flooding materials.
Description:
1. PLC control system touch screen.
2. If coiling wires are ran out, the machine will stop automatically.
3. Automatic centralized grease lubrication.
The machine is supposed to be in continuous and smooth operation, saving much labour force.
Specifications:
Overall Size | 7850×1600 ×2300mm | Mesh Size | 106×120mm |
Power | 22kw | Weight | 14000kg |
Mesh Width | 4300mm | Max Wire Diameter | 4.2mm |
Automatic oil system | |||
PLC control system touch screen(option) | |||
Automatic stop system(option) | |||
specialized pressing device(option) | |||
Infrared ray safety protection device(option) |
A set of gabion box machine includes four main parts: Mesh weaving machine, wire tension roller, mesh winding machine and 6 bars spring coiling mahcine.
Competitive Advantage:
1. Jinlida committed to making gabion mesh making machine, gabion production line for 20 years.
2. All the parts of gabion machine are processed by our own factory; no parts were send to outside to
process, so the quality can be ensured.
3. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our
technician to help install the machines in your country, and also could supply all the spare parts with cost
price if customer need.
