Home > products > Hexagonal Wire Netting Machine > Professional Auto Hexagonal Wire Netting Machine 3kW For Gabion Mesh

Professional Auto Hexagonal Wire Netting Machine 3kW For Gabion Mesh

Product Details

Place of Origin: China

Brand Name: Jinlida

Model Number: LNWL-2055-2

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Competitive price

Packaging Details: Nude packing

Delivery Time: 50 days

Payment Terms: L/C,T/T

Supply Ability: 300 sets/a year

Get Best Price
Highlight:

Wire Netting Weaving Machine

,

Hexagonal Wire Netting Making Machine

Power:
3kw
Usage:
Making Hexagonal Mesh
Warranty:
1 Year
Power:
3kw
Usage:
Making Hexagonal Mesh
Warranty:
1 Year
Professional Auto Hexagonal Wire Netting Machine 3kW For Gabion Mesh

Professional Auto Hexagonal Wire Netting Machine 3kW For Gabion Mesh





Quick Detail:



1) Mesh sizes: 27x41mm
2)Max netting width: 2200mm
3)Max galvanized wire diameter: 1.2mm
4)Power: 3kW
5)Theoretic output: 100m/hr





Descrition:



Light Hexagonal Wire Netting Machine

The machine includes three main parts: mesh weaving machine, spring coiling machine, bobbin machine.

Light Hexagonal Wire Netting Machine is the professional machine to produce small wire diameter of

hexagonal mesh. The mesh is main used as fence, residence and the protecting the garden.





Specifications:



1) Mesh sizes: 27x41mm
2)Max netting width: 2200mm
3)Max galvanized wire diameter: 1.2mm
4)Power: 3kW
5)Theoretic output: 100m/hr
6)Automatic stop system (option): when the coiling finished or wire broken, the machine will stop automatically
7)Infrared ray safety protection system (option)
8)Automatic oil system



Style

Specification

Mesh size

Width

Wire diamater

Twisting

Lines

Spindle Speed

power of motor

Theoretic

output

(mm)

(mm)

(mm)

r

(r/min)

(kw)

(m/h)

LNWL-1015-2

1/2'

15x18

1200

0.8

3

33

3

51

LNWL-1018-2

5/8'

18x5

0.9

3

67

LNWL-1022-2

3/4'

22x33

1.2

3/5

83

LNWL-1027-2

1'

27x41

3/5

100

LNWL-1032-2

1/1/4'

32x52

3/5

122

LNWL-1039-2

1/1/2'

39x61

3

142

LNWL-1055-2

2'

55x70

3

162

LNWL-1078-2

3'

78x86

3/5

194

LNWL-2015-2

1/2'

15x18

2200

0.8

3

33

3

51

LNWL-2018-2

5/8'

18x5

0.9

3

67

LNWL-2022-2

3/4'

22x33

1.2

3/5

83

LNWL-2027-2

1'

27x41

3/5

100

LNWL-2032-2

1/1/4'

32x52

3/5

122

LNWL-2039-2

1/1/2'

39x61

3

142

LNWL-2055-2

2'

55x70

3

162

LNWL-2078-2

3'

78x86

3/5

194





Competitive Advantage:



1. All the parts of gabion machine are processed by our own factory; no parts were sending to outside to

process, so the quality can be ensured.



2. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with

cost price if customer need.
