Hydraulic Stainless Steel Wire Mesh Cutting Machine / Gabion Production Line

Hydraulic Stainless Steel Wire Mesh Cutting Machine / Gabion Production Line

Brand Name:	Jinlida
Model Number:	MSC-100
MOQ:	1
Price:	Competitive price
Delivery Time:	30 days
Payment Terms:	L/C,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

Mesh Cutting Machine

Cutting Lendth:

Condition:

New

Overall Size:

5100*1500*1500mm

Control System:

PLC

Application:

Industrial Metal Cutting

Packaging Details:

Nude packing

Supply Ability:

100 sets/a year

Highlight:

wire mesh making machine

steel wire cutting machine

Product Description

Hydraulic Stainless Steel Wire Mesh Cutting Machine / Gabion Production Line

Quick Detail:

Gabion mesh production line is composed of material testing, PVC coating, netting weaving, wire netting straightening, netting sheet cutting, reinforcing edge, gabion assemblage, packing gabions and transporting gabions.

Description:

1. The machine's frame is rugged, with the return of nitrogen cylinder, it is steady and rapid

2. With stepless travel features, the upper and lower blade's clearance can be adjusted with handle,

it is easy to adjust.

3. Fence and electrical chain to ensure safe operation

4. Closed loop control system is composed of numerical controls and position encoder, it is high speed,

high accuracy, good stability

5. CNC system has the accuracy and automatic detection of a variety of additional features

Applications:

The Gabion Mesh Cutting Machine is using for gabion mesh's cutting; it is an essential machine for gabion

production line. Netting Sheet Cutting Machinery Cutting Sheet without manual work

Specifications:

The Diameter of Wire	4.0mm	Mesh Width	4500mm
Shearing Angle	1°30'	Certification	SGS, TUV
Power	7.5kw	Warranty	1 years
Spindle Speed	1460r/min	Dimension	5400 x 1970 x 1400mm
Belonging	Gabion production line	MOQ	1 Unit
Model Number	QWJ-100	Weight	6000kg
Delivery Time	40days	Port	Shanghai

Competitive Advantage:

1. All the parts of netting sheet cutting machine are processed by our own factory; no parts were sending to

outside to process, so the quality can be ensured.

2. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
