60*80mm Gabion Mesh Making Machine Stone Cage Box For Sustain Bank

Place of Origin China
Brand Name Jinlida
Model Number LNWL4
Minimum Order Quantity 1
Price Competitive price
Packaging Details Nude packing
Delivery Time 40 days
Payment Terms L/C,T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Name Gabion Machine Mesh Size 60*80mm
Mesh Width 3000mm Wire Diameter 2.2-4.2mm
Speed 165m/h Application Sustain Bank
High Light

Gabion Machine For Sustain Bank


pvc wire coating Gabion Machine


Stone Cage Box Gabion Machine

Leave a Message
Product Description

60*80mm Gabion Mesh Making Machine 2*1*1m Stone Cage Box for Sustain Bank



Quick Detail:


1. Gabion mesh machine is one kind of special equipment for twisting metal wire hexagonal mesh with big wire, big mesh and wide breadth.

2. The weaving mesh speed of LNWL4 adds to 60 moves per minute, in this way, efficiency improves one third of old machines.




1. The mesh that 4h series machine weave, the part of twist is longer than 2 series machine. So when cutting netting sheet, it is easy to cut on the twist. In this way, it is beneficial for curling edge with border reinforcement machine if you need.

2. It can weave 3.2mm wire mesh easily like normal machine weave 2.4mm wire mesh, and speed is also quickly as normal style.




1. Adopted with central automatic lubrication system, so as to make feeding guideway to have the good performance for little resistance, little friction, good lubrication and long life etc.

2. PLC control system touch screen is available for the hexagonal wire mesh machine.

3. Automatic stop system saves much labor force.




We can manufacture gabion machine according to your request.

Overall Size 6350×1600 ×2300mm Mesh Size 60×80mm
Power 22kw Weight 12000kg
Mesh Width 3000mm Max Wire Diameter 4.2mm
Automatic oil system
PLC control system touch screen(option)
Automatic stop system(option)
specialized pressing device(option)
Infrared ray safety protection device(option)


The main machine includes four main parts:mesh weaving machine, spring coiling machine, mesh roller machine and wire tension device.

60*80mm Gabion Mesh Making Machine Stone Cage Box For Sustain Bank 0

60*80mm Gabion Mesh Making Machine Stone Cage Box For Sustain Bank 1




The gabion machine is the professional equipment that produces hexagonal mesh, its product is widely used in petroleum, building, farming and chemical engineering industry, keep warm piping and other piping, still be applicable to the river embankment the protection, coast to manage, and the assisting of tunnel engineering and breakwater establish the etc.



Competitive Advantage:


1. All the parts of netting sheet cutting machine are processed by our own factory; no parts were sending to

 outside to process, so the quality can be ensured.


2. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
