Hydraulic PVC Coated Wire Gabion Machine 120mm x 150mm Mesh Size

Hydraulic PVC Coated Wire Gabion Machine 120mm x 150mm Mesh Size

  • High Light

    coiling spring machine

    ,

    Gabion Box Machine

  • Type
    Hydraulic
  • Material
    Pvc Coated Wire
  • Mesh Size
    120mm X 150mm
  • Color
    As You Required
  • Place of Origin
    China
  • Brand Name
    Jinlida
  • Model Number
    LNWL43-120-2ZX
  • Minimum Order Quantity
    1
  • Price
    Competitive price
  • Packaging Details
    Nude packing
  • Delivery Time
    50 days
  • Payment Terms
    L/C,T/T
  • Supply Ability
    200 sets/a year

Hydraulic PVC Coated Wire Gabion Machine 120mm x 150mm Mesh Size

Hydraulic PVC Coated Wire Gabion Machine 120mm x 150mm Mesh Size





Quick Detail:



1.The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh

sizes.

2.The possible coatings are heavily galvanized and zinc.

3.For high corrosion resistance, zinc and PVC coated wire is available.



Description:



New type Double Rack Drive Gabion machine



The design is innovation in China, it can weave 4.0mm wire mesh easily like normal machine weave 2.4mm wire mesh, and speed is also quickly as normal style.



JINLIDA series machine is designed to make hexagonal wire mesh of various widths and mesh sizes.

We have 15 years export experience establishing trade with more than 30 countries, and Maccaferri,

DEACERO, NOVA-S a.s.& DKG and TFS HOLDINGS are our long-standing relationship customers.



Advantages:



1. New type double rack drive gabion machine

2. High efficiency: theoretic output=255M/H

3. PLC control system touch screen(Option)

4. Infrared ray safety(Option)

5. Automatic stop system (Option)

6.Automatic oil system

7. It use seamless steel tube to increase inside diameter , make it put more spring wire so it can save the time of changing spring wire and improve output.

8. The design is innovation in China, it can weave 4.0mm wire mesh easily like normal machine weave 2.4mm wire mesh, and speed is also quickly as normal style.



Pic 1 Gabion machine



Hydraulic PVC Coated Wire Gabion Machine 120mm x 150mm Mesh Size 0

Pic 2 Netting winding machine& wire tension device& spring coiling machine

Hydraulic PVC Coated Wire Gabion Machine 120mm x 150mm Mesh Size 1



Specifications:



Style Mesh size Width Wire diamater Spindle Speed Twist power of motor Theoretic output
(mm) (mm) (mm) (r/min) (r ) (kw) (m/h)
LNWL43-60-2ZX 60X80 4300 1.6-3.2 25 3 22 165
LNWL43-80-2ZX 80X100 1.6-4.0 3 195
LNWL43-100-2ZX 100X120 1.6-4.0 3 225
LNWL43-120-2ZX 120X150 1.6-4.2 20 3 255
LNWL43-60-3ZX 60X80 4300 1.6-3.2 25 5 22 165
LNWL43-80-3ZX 80X100 1.6-4.0 5 195
LNWL43-100-3ZX 100X120 1.6-4.0 5 225
LNWL43-120-3ZX 120X150 1.6-4.2 20 5 255





JINLIDA Series Prduction Line

Hydraulic PVC Coated Wire Gabion Machine 120mm x 150mm Mesh Size 2



Competitive Advantages:



1. All the parts of netting sheet cutting machine are processed by our own factory, no parts were send to

outside to process, so the quality can be ensured.



2. We can provide 12months guarantee for all the equipments, and if customer need, we will arrange our

technician to help install the machines in your country, and also could supply all the spare parts with cost

price if customer need.
