PLC Control Three Twist 15kw Gabion Box Machine

PLC Control Three Twist 15kw Gabion Box Machine

  • High Light

    15kw Gabion Box Machine

    ,

    Three Twist Gabion Box Machine

    ,

    Three Twist gabion making machine

  • Product Name
    Gabion Machine
  • Mesh Size
    80*120mm
  • Mesh Width
    2300mm
  • Power
    15kw
  • Voltage
    415v
  • Twist Number
    Three Twist
  • Brand Name
    Jinlida
  • Certification
    CE, IOS9001
  • Model Number
    LNWL3
  • Minimum Order Quantity
    1 set
  • Packaging Details
    Nude packing and will be fixed in container by iron wire
  • Delivery Time
    40 days
  • Supply Ability
    200 sets/ year

PLC Control Three Twist 15kw Gabion Box Machine



    Brief Introduction

1. The design aims at automatic operation, easy regulation, simple maintenance and high productivity.

2. The LNWL3 series hexagonal mesh machines specifically use rachet mechanism to make mesh drawing roller run orderly.

3. The machine is supposed to be in continuous and smooth operation, saving much labour force.



Specifications

Overall Size 5400×1200 ×2300mm Mesh Size 80mm×120mm
Power 15kw Weight 12795kg
Mesh Width 2300mm Max Wire Diameter 4.2mm
Automatic oil system
PLC control system touch screen(option)
Automatic stop system(option)
specialized pressing device(option)
Infrared ray safety protection device(option)

    Packing&Delivery:



Packing Details: Nude packing and will be fixed in the 40'container by iron wire, make sure it is safe on passage.

Lead Time: 40 days



Principle of Mechanics:

intermediate gear→ eccentric disc→seesaw → pull rod → ratchet mechanism→mesh drawing gear→ mesh drawing roller

PLC Control Three Twist 15kw Gabion Box Machine 0



Competitive Advantages:



1.Precise design of complete machine, compact conformation, handiness and simplicity.



2.All the parts of gabion mesh machine are produced by our Jinlida,no parts were sending outside to produce,so we can guarantee the quality.



3.Jinlida has rich experience and professional skills to meet your needs and satisfy your requirements.
