3 Twist PLC Control Gabion Mesh Machine For Hexagonal Wire Netting Reno Mattress

Product Details

Place of Origin: China

Brand Name: Jinlida

Model Number: LNWL4

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Competitive price

Packaging Details: Nude packing

Delivery Time: 50 days

Payment Terms: L/C,T/T

Supply Ability: 200 sets/year

Get Best Price
High Light:

gabion mesh machine

,

Gabion Box Machine

Name:
Gabion Mesh Machine
Mesh Width:
3300mm
Mesh Size:
66*88mm
Wire Diameter:
2.6-4.0mm
Speed:
165m/h
Application:
Reno Mattress
Name:
Gabion Mesh Machine
Mesh Width:
3300mm
Mesh Size:
66*88mm
Wire Diameter:
2.6-4.0mm
Speed:
165m/h
Application:
Reno Mattress
3 Twist PLC Control Gabion Mesh Machine For Hexagonal Wire Netting Reno Mattress

3 Twist PLC Control Gabion Mesh Machine For Hexagonal Wire Netting Reno Mattress





Quick Detail:



     1. 66*88mm mesh is a good choice for reno mattress.



     2. LNWL4 gabion mesh machine no longer adjust after install, more suitable for the epidemic.



     3. 2.6-4.0mm wire can be used on machine.



Description:



The weaving mesh speed of LNWL4 adds to 60 moves per minute, in this way, efficiency improves one third of old machines.



    1. PLC control system touch screen is available for the hexagonal wire mesh machine.

    2. The machine is supposed to be in continuous and smooth operation, saving much labor force.It has low noise and automatic stop system.

    3. The LNWL4 series mesh weaving machines have been designed to make gabion mesh of various width and mesh size.



Specifications:

-4H/

双绞

double twist

拉网辊

Mesh rollerØ

-4HS/

双绞

double twist

拉网辊

Mesh rollerØ

-4HS/

五绞

three twist

拉网辊

Mesh rollerØ

-4H

双绞捻网速度double twist knitting speed

-4HS

五绞捻网速度

five twist knitting speed

60*85/ 28mm Ø180/ 5

















25 20
66*90/ 28mm Ø191/ 5

















25 20
70*90 /30mm Ø191/ 5 70*90/ 45mm Ø215/ 5 70*105/ 55mm Ø203.8/4 25 20
80*103/ 32mm Ø215 / 5 80*115/ 45mm Ø203/ 4 80*105/ 55mm Ø203/ 4 25 20
88*105/ 32mm Ø218/ 5 88*115/ 45mm Ø203/ 4 88*105/ 55mm Ø203/ 4 25 20
90*100/ 32mm Ø218/ 5 90*115/ 45mm Ø203/ 4 90*105/ 55mm Ø203/ 4 25 20
100*120/ 32mm Ø242/ 5 100*125 /45mm Ø217/ 4 100*115/ 55mm Ø217/ 4 25 20
110*140/ 32mm Ø219/ 4 110*126/ 45mm Ø218/ 4 110*116/ 55mm Ø218/ 4 25 20
120*140/ 32mm Ø219/ 4 120*140/ 45mm Ø295/ 5 120*130/ 55mm Ø295/ 4 25 20
Note:

1. -4H:不带伺服程序控制,-4HS:带伺服程序控制.

-4H: without servo program control, -4HS: with servo program control.

2. Ø拉网辊外径后面-4或-5为圆周上的拉网齿等分.

Mesh roller item: ‘4’ or ‘5’ means thorn nails equal parts number(how many nails rows of one roller ).

3. 网孔规格-32,-45,-55为网孔绞合部分的长度尺寸.

Double twist and five twist item: ‘32mm’, ‘45mm’, ‘55mm’ is twist length.

4. -4H型机设定每分钟理论生产速度为25个双绞网孔.

-4H machine theoretic output: 25 double twist mesh hole every minute.

5. -4HS型机设定每分钟理论生产速度为20个五绞网孔.

-4HS machine theoretic output: 20 five twist mesh hole every minute.



Related Machine



A set of gabion mesh machine is composed of hexagonal wire mesh machine,wire tension device, netting winding machine and spring coiling machine.

3 Twist PLC Control Gabion Mesh Machine For Hexagonal Wire Netting Reno Mattress 0

3 Twist PLC Control Gabion Mesh Machine For Hexagonal Wire Netting Reno Mattress 1  3 Twist PLC Control Gabion Mesh Machine For Hexagonal Wire Netting Reno Mattress 23 Twist PLC Control Gabion Mesh Machine For Hexagonal Wire Netting Reno Mattress 3



Competitive Advantages:



     1. Jinlida series machines are designed to make gabion mesh of various widths and mesh sizes, we can produce the machine as your size.



     2. Every part of gabion mesh machine is high quality, they are assembled by skilled workers who have years of experience.



     3. We offer fine quality, competitive prices,prompt delivery and a satisfying service.
